6 ZONES economical Waterproof walk-through metal detector gate XLD-A
Technical Parameter :
|
Power self-checking Function |
Upon starting up ,the system will automatically diagnose whether the operation is ok or not Automatically display the content of system malfunction |
Operation Method |
1)Chinese/English menu function for choice 2) Computer remote networking. |
Speed |
The fastest speed: 100 people per minute .Detection speed of user-defined adjustment. |
Backlight Time |
Adjustable continual display time: 0 to 99 Seconds |
Detecting Zone |
6 standard zones (default value: 6 zones ) |
Alarm Indication |
1) Alarm time: 1 to 25 seconds. Range of adjustable Volume: 255 Degree. 2)Around the goal post ,can be directly show inspection zones through the LED alarm light ,and accurately show the corresponding height of the body hidden prohibited items. |
Sensitivity Adjustment |
1).Can evenly adjust 255 degree sensitivity of every zone 2).Preset in line with the weight , volume, dimension and position of metal items to exclude false alarm of coins, keys, jewelry and buckles and so on |
Strong anti-jamming capability |
1)Adopting the advanced interactive receiving and transmitting 2) Automatically detecting and tracking by temperature and humidity and compensation technique to be available to different environment and climate, significantly increased anti-jamming capability. |
Networking function(optional) |
.Using RJ-45 network interface, which has no limit in distance ,and improved the defects of the short distance of RS232 network. Configure of dedicated PC software to reach remote parameter setting / inquiry function so that we know work safety of metal detector gate. |
Counting Function |
Intelligent recording people number and alarm counting function that can automatically record the number of people and times of alarm. |
Alarm Recording |
Times of alarm. Anytime can be check. |
Waterproof designs |
use of imported waterproof synthetic material produced by precise technology synthesis |
Place |
can be set using the occasion required random mode (such as airports, entertainment venues, the Court) |
Online help |
Help system placed inside. More easy and intuitive to operate . |
Power supply |
AC85V -264V/50-60HZ |
Consumption power |
20w. Low power consumption and; Low radiation |
Overall dimension |
2220mm (h) x 820mm (w) X 500mm |
Tunnel dimension |
2045mm (h) X 700mm (w) X 500mm |
Weight of the whole machine |
Approximately 68 kg |
Workplace environment |
-20°C+45°C |
1. What is the minimum order quantity?
The MOQ is 1 piece.
2. What is the lead time?
3-5days after T/T payment, for other products please contact us for details.
3. What is the payment term?
The payment term is T/T before shipment.
4: How does your company and factory do regarding quality control?
Every products will be detected after producing and approved by ISO9001 and CE certificate.
