Eas anti-theft devices Model XLD-T06
acrylic RF system/Wide Aisle RF System
Ideal for chief exits of clothing stores,supermarkets and shopping plaza,Optimum for shopping sites where mainly use hard tag
Detail
The Wide Aisle system is specially designed to ensure superior detection for wide aisle installations. The detection range can be up to 1.5-2.8M with the appropriate 8.2 MHz labels or tags. The child-proof design of the Wide Aisle shows an overall appearance which is both pleasing and robust.
The Wide Aisle is fitted with the latest optically (wired) slaved transmitter and a receiver using sophisticated digital signal processing. This ensures that the signal of disposable labels (hard-tags) can be reliably distinguished from potential noise sources and guarantees maximum detection performance, yet minimizing false alarms. The system is fully compatible with all 8.2MHz hard tags and disposable labels.
For retailers to whom maximum system detection range is critical, along with contemporary appearance, the newly designed Wide Aisle is definitely the system of choice.
Electrical Specifications: | Operating Frequency 8.2 MHz ( ±10% ) |
Synchronization Input: | 1 x Opto Receiver (plug in, optional) |
| |
Synchronization Output: | 2 x Opto Transmitter (plug in, optional) |
| |
Receiver Technology: | Digital Signal Processor (DSP) |
Power Supply: | 24 VDC / 1.5A, Linear Power Supply |
Alarm Light: | Light Emitting Diodes ( LED ) |
Alarm Sound: | Buzzer, 90db at 1m ( 3.3ft ) |
Mechanical Specifications: | Height 1620 mm ( 5.31ft ) |
Material: | Clear Acrylic |
