EAS RF Shop Anti-theft Security Alarm Gate

Model XLD-T05  EAS  System Mono Antenna

Ideal for chief exits of clothing stores, supermarkets and shopping plazas. Optimum for shopping sites where mainly use hard tags.

1PC/CTN, 174X54X16CM, 26.0KGS/CTN
1PC/WOODEN CASE, 179X56X17CM, 40KGS/WOODEN CASE

Model: XLD-T05

Material: imported Acrylic

H 1600mm, W 400mm

The technique character

The most advanced digital signal dispose technic.(possess knowledge property right.

Dynamic yawp restrain technique.

Automatic plus control techinique.

Fixing debugging is simple.

The electrical source power consumption is low.

The sphere of protector is wide: a branch antenna can protect the sphere from 1.2m-2.2m.

Work temperature: 0°C~40°C

Deposited temperature : 40°C~60°C

Comparatively  humidity: 5°C~95°C without cooling condensation

Working voltage: 18VAC.

Working current: less 600mA

Insurance: 250V, 1A defer mode.

Working frequency: 7.8MHz ~ 8.4MHz

Detecting speed: 2m/s

Input voltage: 220VAC

frequency: 50/60Hz   Range: 160VAC~242VAC

Output voltage 18VAC  1400mA

New generation EAS system, only one pedestal antenna can serve double sides. Adopting Auto-adaption Electronic magnetic circumstance technology, false alarm is minimized to lower degree.
Suggested place: high-class garment stores, shopping malls and plazas.
Low rate of false alarm: the 5th DSP technology, FPJA
EAS adjustment: software/ by hand.
