Electronic Door RFID Card Lock System in Hotel Door
- 1000000 Piece / Pieces per Month
- Guangzhou/ Hong Kong
- L/C D/P D/A Credit Card PayPal T/T
Product Details
Brand Name: | DAILY RFID | Model Number: | RFID Card Lock System |
Product Description
Electronic Door RFID Card Lock System in Hotel Door
Our website is
1. Fancy features:
Stainless steel color w/PVD coating
U.S standard/ European standard , 5 latch mortise
M1 or Temic card
Mater card/Emergency card/Building card/floor card/cleaning card/maintainance card......
CE, FCC, ROHS,BHMA.Fire proof certification
SDK , PMS available
Fidelio opera registered. interface with most of the PMS system
Passed BHMA&UL 800,000times circling TEST
2.Electronic hotel lock specification.
1.Materials:ss304 electronic hotel lock
nology:proximity RFID
lor:silver and golden for your option .
4.warranty: 2 years !
No. | Description | Technical Parameters |
1 | Power: | 4pcs #5 AA alkaline batteries, |
2 | Static Electric Current: | Static Load<10Ua,Working Load: 100Ma-150Ma |
3 | Working Electric Current: | 100-300mA |
4 | Card type | M1 card or temic card |
5 | Battery Life: | 18 months’ duration |
6 | Lock operation records | 240pcs |
7 | Insert Reliability: | No mistake even inserted continuously 2000 times |
8 | Insert Guarantee: | Still work well after inserting any illegal card |
9 | Low Voltage Warning: | low Battery Voltage warning. (Lower than 3.5 V) |
10 | mortise | ANSI Standard mortise/Euro standard |
11 | Humidity | 20%-90% |
12 | Working tempreture | -50°C-80°C |
13 | Suitable door | Wooden door, fire-proof door, metal door and so on. |
3.Lock LED Error Indication
1. Red light flashing two times with two “beeps”, it means the card is belong to other doors. Or when using the staff card-→opening times to open the lock and the times has already been used up, the red light will flash two times also.
2. Red light flashing three times with three “beeps”, it means the card time is not match with the lock time.
3. Red light flashing four times with four “beeps”, it means the lock haven’t been authorized.
4. Red light flashing five times with five “beeps”, it means the card has been suspended.
5. Red light flashing six times with six “beeps”, it means the lock is deadbolt working.
6. Red light flashing seven times with seven “beeps”, it means the lock was been blocked by the block card. In this case, only master card can open the lock.
7. Red light flashing eight times with eight “beeps”, it means the lock was authorized by the authorization card issued from another system. In this case, if you don’t know the code, you need to reauthorize the lock mandatorily.
4.Why choose us?
1. With more than 10 years experience in hotel projects. Such as hotel locks,minibars,safes,telephones...etc.
2.Well cooperated with lots of famous hotels in the past years,like Hiton , Starwood,Best Western...etc.
3.With the advanced RFID technology.
4.There are two own factories in China.
5. Have a good development prospects.
6. Professional after-sales service.Help you solve the problems in time.
FAQ
How does the lock get powered and how long can it last?
The lock is powered with 4 AA battery,use 4 new brand battery can open more than 10,000 times.last about 18 months.
What should do when battery is run out?
The lock will beep to prompt when power is lower than 3.5V,please change the battery when it alarm. You can still use the card open about 200 times when it prompt. If the battery is not work,you can use backup key to open the door.
How to open the lock if the card is not work or there is something wrong with the electronic part?
Each lock are equipped with 2 mechanical keys,you can open door with those keys.
If OEM OR ODM orders accepted ?
Yes, we are accept OEM or ODM orders .
What's the MOQ and if can send sample to have a test?
Without MOQ request. It is available to offer the sample for your checking first.
What 's the door thickness required for those mortise?
Our lock mortise is suitable for the door thinkness with 25~60mm.
How about your software, is the PMS possible?
We have made the software upgrade according to the hotel's need. It is very intelligent and convenient.We can offer you SDK, PMS support. Also we have registered the Fideo/Opera !
What's the delivery time?
Samples should be within 3 workdays,quantity order takes about 3-20 days.
Are your factory is experienced in this field?
We have more than 10 years experience in this field.
What certification do you have?
CE, FCC, UL, ISO , ROHS
When something wrong happened with your goods beyong our control , how should do ?
Contact our Professional Service Sector, they will offer you the help instantly.
Do you have any branches at home and abroad?
For now, we have a big factory with 45,000 square meters in Guangzhou, Guangdong. And the headoffice located in Guangzhou, Guangdong. Also have clients in most countries round the world.
Any other questions? Please feel free to contact me !
