Home > Products > Screw and Barrel spare parts > CE Twin Screw Extruder Segment Barrel
CE Twin Screw Extruder Segment Barrel
- 1000 Piece / Pieces per Month
- Nanjing or Shanghai
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | Haisi | Model Number: | TSE |
Standard: | ISO |
Product Description
We are manufacturer of twin screw extruder, also can supply all the spare parts.
like screw, barrel, feeder,die head electric controller and gearbox.
Description:
The flexible modular principle is realized with screw barrel sections from the wide range ofdifferent designs possible. Fast, intensive and uniform heating ofthe screw barrel section is ensured by electrical heaters. The barrel sections are cooled with water, by means ofan internal bore system, with bores arranged close to the inside barrel wall.
Base Material | 1) 38CrMoAlA(JIS SACM645) 2)Cr12MOV(JIS SKD-11) 2) 4Cr5MoSiV1(JIS SKD-61) 4) 42CrMo(AISI 4140) | ||
Bimetallic Alloy Material | 1)Fe-based alloy 2)Ni-based alloy/Deloro alloy 3)Co-based alloy 4)NiCo-based alloy 5)Tungsten carbide/Wolfram carbide | ||
Surface Treatment | |||
1.Heat treatment | 2.High frequency treatment | ||
3.Nitriding treatment | Nitrided case depth: 0.50-0.80mm | ||
Nitrided hardness: HV850-1020 (HRC57-65) | |||
4.Hard chrome plating treatment | Chromium-plating layer depth: 0.05-0.10mm | ||
Chromium-plating layer hardness: more than 950HV | |||
5Nickel alloy plating treatment | Bimetallic barrel: centrifugal casting (Inlay alloy) | ||
Bimetallic screw: plasma alloy coating spraying | |||
Bimetallic layer depth: 0.8-2.0mm | |||
Bimetallic layer hardness: HRC 57-72 | |||
Basic Information | |||
Nitride Brittleness | ≤Grade Two | ||
Surface Roughness | Ra0.4um | ||
Screw Straightness | 0.015mm | ||
Hardness after hardening and tempering | 0.025~0.10mm | ||
Material Application | 1)General plastics | ||
2)ABS,PA,PC,PE,PET,PS,PU,PVC,U-PVC | |||
3) PA+GF (Glass Fiber) | |||
4)Flame-resistant reinforced plastics | |||
5)Modified engineering plastics | |||
6)All kinds of mixed recycled materials | |||
General Terms | Means of transport: Ocean, Air, Express | ||
Production time: 20-25 days after order |
Our machine is fisrt painted with anticorrosive oil, and then wrapped in the plastic film before it is finally packed in the wooden case.
Company Information
Nanjing Haisi Extrusion Equipment Co., Ltd. has a professional sales team, personal contact with customers, regular reminders and solve installation, maintenance, repair and other problems encountered by customers in the mechanical operation of the equipment failure analysis and quick to do the maintenance program, in any country and region can get our professional and technical personnel of the most timely and quality service.
Ce and ISO 9001 Certificates
Service Stystem
Before-sale
• Introduce products in detail • Recommend suitable solution • Offer test
During manufacturing
• Provide layout and engineering conditions • Offer screw plan and related documents
• Inform the project processing status • Insure the product designed in accordance with technical document
After-sale
• Provide installation, commissioning and training • Offer spare parts
• Provide necessary technical support and update information.
1. Q: How about Haisi?
R: Nanjing Haisi Extrusion Extrusion Equipment Co., Ltd. is a High-Tech company. Our firm is composed of a strong team which has substantial experience in R&D, manufacture, technique and service, and has specialized in extruder industry for ten years, leading screw barrel manufacturer in China.
2. Q: What's Haisi capacity?
R: Our company is in strict accordance with CE and ISO9001 quality certification system. there are over 200 models of extruders and spare parts.
3. Q: What's the delivery time?
R: For regular size, we have finished stock and semi-finished stock, 2 weeks max are enough for customized, normally 3~4 weeks.
4. Q: Where is Haisi factory and how to reach there?
R: At Lishui, Nanjing, Jiangsu Province. If you want to visit us, we can pick you up in the airpor or train station.
5. Q: How to contact with us?
R: Plz reply to me directly if you have any question.
