Double Channel Full Body Security X Ray Scanner JH-5010DC
Main Features:
- Dual-channel,Human body with package synchronization.
- Detecting the full ranges:can inspect the foreign matter concealed inside or outside of human body, but X backscatter and millimeter wave detector can only inspect the foreign matter and metal concealed outside of human body.
- Protection of personal privacy:uses mini dose of x-ray radiation technology without showing human privacy, but X backscatter detectors and millimeter-wave detectors show human privacy, a definite invasion of privacy.
- High inspection efficiency:time per inspection needs less than 2 seconds, but inspection times of other various brands need more than 10 seconds,suitable for places with a large flow of people to detect uninterruptedly, but other detectors do not have this function.
-
Inspection of low dose NB:Dose per inspection is less than 0.05,the Lowest inspection dose closely approximate to natural radiation.
Technical Specification:
1) Per time detecting dose <0.05µGy,at present it is the lowest at the world.
2) Non-closed micro-dose transmission type X-ray radiation protection of human safety testing equipment: Protective boundaries any leak smaller 0.69 μ Gy/h (better than the industry standard of 2.5 μ Gy).
3) Time per inspection 1.5s-3.0s,better than the industry standard of 15s.
4) Detection efficiency:up to 1200 times per hour.
5) Wire display 40AWG,can distinguish single solid-core copper wires of diameter 0.0787mm (better than the industry standard 0.127mm).
6) Spatial resolution: resolution is less than 1mm (better than the industry standard 1.3mm)
7) Inspection method: continuous loop detection.
8) Protective devices: the unique triple protective devices, leak dose only 1/4 of the industry safety standards, better protect the workers health and safety
Installation Data:
Power 1000W
Voltage 220VAC
Frequency 50Hz/60Hz
Weight 850KG
External dimension : 2600×2100×2600 mm
Passage way dimension :2600×500×260 mm
Baggage passage dimension:2600×500×900 mm
Operating temperature: -5℃~+40℃/10%~90%
Hardware systems:
Basic configuration:
the central control system of dual-channel,
dual-channel data transmission systems,
dual-channel data acquisition system,
dual circulation system,
security protection shield system,
leakage protection system,
dual protective bracket.
Optional configuration:
moisture-proof system,
UPS uninterruptible power supply systems,
dust control system,
corrosion protection system,
high temperature protection system,
Video guide shows system.
Software system:
Basic configuration:
WLP weak photon perspective systems,
WLC weak photon tomography systems,
single-image processing system,
safety interlocking brake system,
intelligent storage retrieval systems.
Optional configuration:
Remote management system,
intelligent inspection system,
user management systems,
face recognition systems,
automatic alarm systems,
identity RDIF identification systems,
multi-screen display system.
