automatic identification of threats or modifications to a vehicle’s undercarriage.
It can quickly and accurately identify threats , contraband objects and stowaway
who are hidden at the bottom.
Features:
l Auto digital line scan, high-resolution undercarriage imaging.
l High automation, easy to be used.
l Applicable to variety of vehicles, wide vision.
l Test will be completed during the vehicle maneuvers without stopping, adapted to different speed.
l Undercarriage image can be stored, retrieved, searched or compared with other images.
l A variety of image processing methods: enlarge, stretching and cutting.
l Multi entrance management model, management, and statistics of entering and exiting vehicles.
l Flexible detection process can be made on site to satisfy the needs of various work conditions.
Advantage of UVSS:
l No need to park vehicle, can bear speed below 30km/h
l Whole image display ion monitor, can zoom, playback, sign in the images.
l Operator can zoom and save image
Main Technical Indexes:
Embedded Under Vehicle Scanning Parts
1. Camera: Sensor: line scans CCD
2. Resolution:5000* 2048 pixels, Power Supply: 24VDC, 3A
2. Illumination: LED, Power Supply: 24VDC, 150W
3. Size: 1200mm x 350mm
4. Water-proof grade: IP68
5. Operating Temperature Range: -20 °c to +70 °c
Controller
1. Input: 2 channels induction coil
2. Output: 1 Channel switch type 12VDC
3. Communication port: RS485, 1000M Ethernet (Optional)
4. Operating temperature:-10°C to 55°C
System Host
1. Brand: Grantech (SYM76941 VGGA)
2. CPU: Intel (R) Celeron (R) CPU E3400, 2.6GHz 2.59GHz
3. Memory: 2G (optional 4G)
4. Graphics :512M
5. Hard Disk: SATA2 Hard Disk 500G
