JH-EPD001 EXPLOSIVE DETECTOR

Specifications

Alarm Mode Buzzer and visual display in English
Dimension: 430x113x205mm
Weight 4.0 kg including battery

This Portable Explosive Detector adopts pseudo random sequence ion door-opening technology and Hardmard algorithm. It adopts this technology firstly among the same type devices all over the world, which improve its SNR and anti-jamming capacity greatly, reduce false alarm rate efficiently.

The operation of this device is very humanized and the special sample-taking pen may prevent the test paper from operator's contamination. It has English menu, color display, convenient removable quick charging battery and storage for 5000 alarm records. The network and USB sockets can meet the sample adding and Internet connecting demands.



• Independent Research & Development


• Patent Technology: pseudo random sequence ion door-opening technology and Hardmard algorithm


• Unique Feature: can show the name of explosives on LCD display.


• Storage of Records: 5000


• Renewable Database and Operation Program


• External USB and Network Port
• Special Sampling Pen: avoid operational pollution


• Sample Collection: sniff collection  and wipe collection


• Chinese and English Menu


• Small Size and Light Weight



Technology	IMS,Hardmard Transfer
Detecting Capability	Black Powders, Ammonium Nitrate (AN), TNT, AN-TNT, RDX, PETN, HMX, Tetryl, C4, TATP, SEMTEX etc. (The explosive database can updated for new explosive)
Sensitivity	10-9 g
False Alarm Rate	1%
Sampling Mode	Air sample collection of vapour particle and surface wipe of trace particle
Warm-up Time	10 minutes
Analysis Time	4~10s
Calibration Time	30s
Alarm Mode	Buzzer and visual display in English
Dimension(mm)	430×113×205
Weight	4.0 kg (including battery)
Power Supply	AC 220V @50/60Hz or DC
Temperature	-20°C~55°C
Working Humidity	RH 95%
Display	Chinese and English Menu, 3.5 inches TFT color screen
Connector	Net-port or USB-port
