Digital metal detector machine, garment processing pipeline metal detector
Scope of application:
EJH-28 is widely used for detecting the needles and metal chips inside the garment, textile, footwear, apparel and accessories etc. It has a good detecting sensitivity in detecting ferrous metal, non-ferrous products and stainless steel
Product characteristic:
1: Stainless steel shell , anti-erosion and long life span .
2: The conveyor belt is made of nonpoisonous material
3: Strong transport drive, all the products below 25kg can be conveyed to be checked.
4; Quick convey speed, it is specially suitable for pipeline operation.
5: When sensor detect a broken needle or over a diameter 0.8mm iron ball, buzzer will sound and conveyor belt will stop. After that, detected products will be return at hand.
6:The performance of the belt conveyer is complied with the American food sanitation standard (FDA), it can be used for transporting the unpacked food directly.
7: Can match the pipeline operation or automatic control device.
8. Good waterproof, dustproof performance.
Main Features:
LCD display & DSP digital signal processing technology
Recording and memory function: able to store up to 20 kinds of different products. Dual-channel and dual-frequency detecting to detect Fe and non-ferrous metals like stainless steel respectively.
Recording and memory function: able to store up to 20 kinds of different products.
360 degree phase adjustment technology adopted to decrease product effect and improve sensitivity in non-ferrous metal detecting.
With high stability: no alarm even if being hammered. Can be integrated into production line or automatic equipment.
Way of alarming: sound and light alarm, stop running automatically.
Technical parameters:
1. Inspection window size:
Normal size of inspection window(mm): 120(H)X400(W)
Normal length of conveyor: 1800mm, normal height of conveyor to ground: 650mm
Remark: The measures of the sizes can be designed according customer’s requirement.
2: Sensitivity:Diameter of 0.8 mm steel ball, weight of 1.2-1.5g Lead, copper and other globular metal parts.
3: Electrical source: 220V 50Hz
4: Power : 120W
5: Alarm: Audible and visual alarm, automatic stop
6: Normal Size(mm): 1740(L)X900(W)X1030(H)
7: Gross Weight: approx 370Kgs Net Weight: Around 310kgs.
Table of Sensitivity
25*8cm 30*10cm 40*15cm 50*25cm 60*10cm 60*35cm
FE ≥0.5mm ≥0.8mm ≥1.0mm ≥1.5mm ≥1.0mm ≥2.0mm
SUS ≥1.2mm ≥1.5mm ≥2.0mm ≥3.0mm ≥2.0mm ≥4.0mm
Remark: the above data is empty-loaded machine sensitivity. The real sensitivity will be lower on condition of different products being tested.
