sausage casing tying machine/sausage production line

Specifications

1.sus 304 stainless steel
2.sausage stuffer+sausage casing tying machine
3.max capacity:1500pieces of sausage per min.



HIGH-SPEED TYING MACHINE GNJ-1500







Product Advantages:



1. This machine adopts high quality stainless steel as material, and twisting speed control adopts frequency



conversion, high efficiency and energy saving.



2. It is equipped with touch screen and PLC, applicable for high speed twisting of protein casing product.



3. This machine features reliable length fixing and strong water-proof performance, easy to clean.







Main technical parameters:





• Twisting speed: the twisting speed up to 1500time/min.





• Twisting length: 25-200mm





• Equipment power: 3.7kw





• Power: three-phrase four-wire 380v 50HZ





• Air pressure: 0.4-0.8Mpa



• Dimension: 1365*1100*580mm(length*width*height)





On-line operation:



This machine can be connected with various sausage filler. The sausage filler is connected with high-speed



twisting machine by high-pressure pose. During operation, the sausage filler selects direct filling mode and



the filling quantity is adjusted as per the twisting speed.
