Dongye multi- function Mini Wheel Loader with CE Certified
- 10 Set / Sets per Month
- qingdao
- T/T
Product Details
Condition: | New | Brand Name: | Dongyue | Model Number: | ZL08A/B |
Place of Origin: | Shandong, China | Type: | Front Loader | Moving Type: | Wheel Loader |
Dimension(Long * Breadth * High): | 4,800x1,600x2,700mm | Rated Load: | 800kg | Certification: | ce |
Warranty: | 6 month | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
1.mini multi function2.CE certificate
3.rated speed 2200r/m
4.rated power 17kw
5.chaichai engine model
Multi-function mini wheel loader for sale in china
Rated loading weight: 800kg
Rated bucket capacity: 0.4CBM
Bucket width: 1300mm
Track base: 1160mm
Wheel base: 1620mm
Min. swerve diameter: 3000mm
Min. ground clearance: 240mm
Dump height fully raised: 2300mm
Reach fully raised: 900mm
Lifting time: 4.5s
Hydraulic cycle time: 9s
Max. tilt angle: 300
Max. bucket breakout force, lift cylinder: 22.5KN
Driving mode: Four-wheel drive
Operating weight: 2000kg
Dimension(L*W*H): 4800*1600*2700mm
Engine model: CHANGCHAI L24
Engine type: In-line arrangement, water cooled, one-cycle diesel Engine
Engine starting mode: Electric
Rated speeds: 2200rpm
Rated power: 17kw
Brake mode: Four-wheel hydraulic spread-shoed brake
Steering system pressure: 10Mpa
Work system pressure: 16Mpa
Color: According to the requirements of customer
Packaging details: Nude package, 3Units/40's HQ
Supply ability: 100 units per month
1.Using direct injection diesel engine as power, with easy startup and low oil consumption 2.Using special drive axle, with strong ability to overcome obstacle 3.Chassis uses hinged structure, with small turning radius and flexible turning, which applies to the operation in narrow space 4.This machine uses hydraulic operation, with simple structure, convenient operation, good performance and reliable quality 5.Widely applying to the construction of agricultural engineering and small and medium building such as road, coal mine, brickyard, urban construction, kiln factory, stone material factory, prefabricated cement parts factory, etc. |
products photos:
