Fresh Air Heat Pump Air Conditioning Machine With Heat Recovery

Specifications

Fresh air Heat pump Air conditioning machine with heat recovery

Technical parameters

Configeuration

1. Crossflow heat exchanger

-Made of Aluminum, cross flow passages, sensible heat exchanger.

2. Fresh air filters

Triple filtration to ensure air cleanness, G4+F7+H10.
Aluminum frame, solid, stable, ametabolic and anti corrosive.
3. Return air filter

Nonwoven material, G4 class, filtering return air.
Aluminum frame, solid, stable, ametabolic and anti corrosive.
4. Bypass system

By adjusting the opening angle, different fresh air volume can go through theheat exchanger and by-pass synchronously. When it’s opened completely, the air goes without passing the heat exchanger.
5. Compressors

 Made by Panasonic, rated cooling capacity is 2410W.
R410a refrigerant, environment friendly.
6. Evaporator

Plate fin heat exchanger, with coated hydrophilic fins.
7. Connection box

Circuit board, core of intelligent control system
Power switch, power supply to the compressor, fans and by-pass
Wiring terminal, easy access for field connection
8. Electrical heater
1200W power controlled by the intelligent set program signal.

9. Drain tray

Made of coated galvanized steel, collecting the drain water from heat exchanger, evaporator and condenser.
10. Drain pump
 Integrated with ball cock to test the water level, the water is drain out automatically if the water is full.
Dimensions Technicalparameters

Controllerdescription
