Home > Tools & Hardware > Hydraulic Parts > Hydraulic Cylinder > Competitive Hydraulic Lift Telescopic Cylinder For Tipper Truck
US$ 500 - 6,000
MOQ: 1 Piece
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Structure:
Piston Cylinder
Power:
Hydraulic
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
5 Stage Telescopic Hydraulic Cylinder for Dump Truck/hydraulic Tipping SystemUS$ 521 - 1,500MOQ: 1 Piece -
Professional Good Quality Single Acting Hydraulic CylinderUS$ 521 - 6,000MOQ: 5 Pieces
-
Telescopic Cylinder System Including Tank, Hose, and so onUS$ 500 - 3,000MOQ: 5 Pieces
-
HYVA Type Telescopic Hydraulic Cylinder Used for Dump Truck/Tipper/TrailerUS$ 408 - 1,388MOQ: 1 Piece
-
FEE Type Dump Trailer Telescopic Hydraulic CylinderUS$ 800 - 3,000MOQ: 5 Pieces
Standard or Nonstandard
Standard
Structure
Piston Cylinder
Power
Hydraulic
Body Material
Steel
Maximum Stroke
3880-9030mm
Shaft Diameter
129-220mm
Place of Origin
Shandong, China
Model Number
telescopic hydraulic cylinder
Brand Name
HCIC
Telescopic Hydraulic Cylinder
Cylinder Tube: Seamless Honed Tube;
Seal Kits:Parke/Hallite/NOK;
Paint: Ballblast;
Processing Machinery: CNC Lathe;
Characteristic:
- Dimension is same to Hyva type.
- Cylinder tube material is high quality 27SiMn steel.
- Cylinder tube is seamless honed tube, hard chrome plating.
- Earring material is 45# steel.
- Coat for FC type material is 20# steel.
- Seal kits are Hallite from UK.
- Tolerance of all cylinder tubes: H9/F8
- Paint is anti-corrosive primer+finish;
- Warranty is 12 months.
- We can also supply whole hydraulic system for dump truck.
Ptoduction List:
| Specification of Standard Products for Dump Truck | |||||
| Model | Extended Stages | Working Pressure | Max.Stage Diameter | Max.stroke | Lifting Capacity |
| 129-3E-3880 | 3 | 16-19 MPa | 129mm | 3880mm | 20-35 ton |
| 149-3E-3880 | 3 | 16-19 MPa | 149mm | 3880mm | 25-45 ton |
| 149-3E-4280 | 3 | 16-19 MPa | 149mm | 4280mm | 25-45 ton |
| 149-4E-3880 | 4 | 16-19 MPa | 149mm | 3880mm | 25-40 ton |
| 149-4E-4280 | 4 | 16-19 MPa | 149mm | 4280mm | 25-40 ton |
| 169-4E-4280 | 4 | 16-19 MPa | 169mm | 4280mm | 30-50 ton |
| 169-4E-4640 | 4 | 16-19 MPa | 169mm | 4640mm | 32-55 ton |
| 169-4E-5000 | 4 | 16-19 MPa | 169mm | 5000mm | 32-60 ton |
| 169-4E-5180 | 4 | 16-19 MPa | 169mm | 5180mm | 32-60 ton |
| 169-4E-5390 | 4 | 16-19 MPa | 169mm | 5390mm | 32-60 ton |
| 169-4E-5460 | 4 | 16-19 MPa | 169mm | 5460mm | 32-60 ton |
| 185-4E-4280 | 4 | 16-19 MPa | 185mm | 4280mm | 25-45 ton |
| 185-4E-4640 | 4 | 16-19 MPa | 185mm | 4640mm | 30-45 ton |
| 185-4E-5000 | 4 | 16-19 MPa | 185mm | 5000mm | 32-50 ton |
| 185-4E-5390 | 4 | 16-19 MPa | 185mm | 5390mm | 40-60 ton |
| 185-4E-5460 | 4 | 16-19 MPa | 185mm | 5460mm | 40-65 ton |
| 185-4E-5780 | 4 | 16-19 MPa | 185mm | 5780mm | 45-70 ton |
| 185-4E-6000 | 4 | 16-19 MPa | 185mm | 6000mm | 50-80 ton |
| 191-5E-5780 | 5 | 16-19 MPa | 191mm | 5780mm | 40-70 ton |
| 191-5E-6200 | 5 | 16-19 MPa | 191mm | 6200mm | 45-80 ton |
| 191-5E-7130 | 5 | 16-19 MPa | 191mm | 7130mm | 50-85 ton |
| 191-5E-9030 | 5 | 16-19 MPa | 191mm | 9030mm | 55-90 ton |
| 220-5E-7130 | 5 | 16-19 MPa | 220mm | 7130mm | 65-100 ton |
| 220-5E-9030 | 5 | 16-19 MPa | 220mm | 9030mm | 65-100 ton |
| You are also welcome to tell us your requirement, we will design accordingly | |||||
Pictures:
