Portable Handy Digital Sound Noise Level Meter Decibel Pressure Logger

Name: Portable Handy Digital Sound Noise Level Meter Decibel Pressure Logger
Brand: Lanho
SKU: 140507096

US$ 8 - 16 MOQ: 100 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Lanho

Model Number:

LO303

Shenzhen Lanho Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Lanho

Model Number LO303

Specifications

Two equivalent weighted sound pressure levels, A and C
Fast and Slow dynamic characteristics modes

Features:

Two equivalent weighted sound pressure levels, A and C
Fast and Slow dynamic characteristics modes
Max locked function has the maximum value, after the stent-in-one unique, easy to use
AC Analog Signed Output for frequency analyzer level recorder or X-Y axis, FFT analyzer, graphic recorder, etc. to do statistical analysis of data logger
Auto power off function
Low battery indicator
Overload prompts
Portable, easy to use and handy
Instantaneous sound measure function
Tripod Mounting option
Passed the high standards of IEC651 TYPE 2 & ANSI S1.4 TYPE 2 for sound level meters

Specification:

Sound Level: 40 ~ 130 dB With Level Selecting Button Switches
level 1: 40 ~ 70dB
level 2: 60 ~ 90dB
level 3: 80 ~ 110dB
level 4: 100 ~ 130dB
level 5: 40 ~ 130dB
Accuracy: ±2dB (under reference condition)
Measuring Level: 40~130dBA, 40~130dBC
Frequency Range: 31.5 Hz ~ 8.5 kHz
Linearity/Dynamic Range: 30dB
Frequency weighting: A and C features
Digital LCD: 45 x 35mm with 4 digits, Resolution: 0.1dB, Display: 0.5 secretary
Sampling Rate: 2 times/second
Dynamic Characteristic (Time weighting): FAST (high speed) / SLOW (low speed)
1 bar graph represents 1dB in the Analog Bar Graph
Bar Graph: 50dB scale at 1dB step for monitoring current sound pressure level display period of 50mS
Level Ranges: 40 ~ 70dB, 60 ~ 90dB, 80 ~ 110dB, 100 ~ 130dB, 40 ~ 130dB
Load indication: Use the symbol OVER (indicating over range) and UNDER (indicating less than lower limit of the range)
AC output: 0.707 Vrms at FS output impedance approx. 600Ω
Microphone: 1/2 inch electret condenser microphone
Maximum Hold
Working Environment: Temperature: 0~40°C (32~104°F), Humidity: 10~70% RH
Storage Environment:Temperature: -10~50°C (14~122°F) , Humidity: 10~80% RH
Power Supply: 6F22 9V alkaline cells/battery or DC 9V 100mA
