Airplane engine heating gas heater

Specifications

Airplane engine heating gas heater
1. 140kw-195kw high output heater
2. huge hot air up to 14000m3/h
3. Riello burner

We supply our Helios series heaters for 2014 The winter Olympics in Sochi







Airplane engine heating gas heater





Airplane engine heating gas heater(Helios serious) is of top quality of indirect fired heater, having the independent combustor, adopt three pass heat exchanger to make sure more thant 90% heat to be used, this thermal efficiency is the highest one among other congeneric product. Helios can output 10000 cubic meters hot airs per hour, the clean hot air can even be breathed. Helios can work at any climate conditions. As meet ergonomic design, it can be easily moved around. Helios respect strong, efficient and reliable.







Airplane engine heating gas heater charactors:

1. Standard configuration is independent diesel burner, can also choose liquefied petroleum gas or natural gas burner
2. Three pass heat exchanger, isolate exhaust air from heated air, keep output clean hot air
3. Waterproofing and insulation Control box, can be used at high humidity environment
4. Simple to use and have multiple safety protection devices
5. Have wheels and handles, easy to move
6. Equipped with axial-flow blower, fan and motor connected directly, motor free maintenance







Airplane engine heating gas heater accessory:

1. Fuel preheater: can preheat diesel in low temperatures, make burning sufficient
2. 1000L Explosion-proof oil drum: reach european diesel storage standards, anti-static, can run over a long time
3. PVC air duct: easy to convey hot air to everywhere
4. PE air duct: economic and practical blast pipe
5. Y type air outlet: Can connect two blast pipe the same time
6. 4 direction air outlet: can connect 4 blast pipe the same time
7. Temperature controller: control indoor temperature, save operation cost as well











Airplane engine heating gas heater specifications:

Model	Helios140	Helios170	Helios150C	Helios200C
Heat output (kcal/h)	120.400	149.200	124.700	166.700
Heat output (Btu/h)	477747	592026	494810	661466
Heat output (kw)	140	174	145	195
Efficiency(%)	89.7	90.3	90.3	90.3
Air output (m3/h)	11000	14000	11000	14000
Air pressure(mmH20)	9	9	52	53
Absorbed power(W)	2300	3100	2300	3100
Voltage (V/Hz)	230/50	400/50	400/50	400/50
Weight ( kg)	235	330	295	400
Stack Dia(mm)	200	250	200	250
Air Outlet Dia(mm)	520	690	520	690
Size(mm)	1945×840×1420	2445×1055×1670	2120×840×1420	2655×1065×1670
