Cheapest Automatic Wood Axe Handle Machinery
1.Machine introduction of Cheapest Automatic Wood Axe Handle Machinery:
This Cheapest Automatic Wood Axe Handle Machinery can make round wood stick from wood with irregular shape. The final round wood stick can be handle for shovel,hoe, broom,mop, rolling pin and so on.
2.Production line of Cheapest Automatic Wood Axe Handle Machinery:
This Cheapest Automatic Wood Axe Handle Machinery prodution line includes 4 machines.
1). wood saw
This wood saw is used to cut the wood board into pieces quadrate wood stick. Then this quadrate wood stick can be used to make round wood stick.
Model Item | HTO-MJ014 |
Power | 5.5kw |
Dimension | 850*8001050mm |
Motor speed | 6m/min |
Working plate area | 430mm |
Main axis length | 360mm |
Machine weight | 240kg |
2). axe handle making machine
This round wood stick making machine can cut the quadrate wood stick into round wood sticks.
Model | HTO-YB35 | HTO-YB60 |
Wood diameter | 5-35mm | 15-60mm |
Wood stick length | >27cm | >27cm |
Capacity | 480 sticks/h (1m/stick) | 625 sticks/h |
Voltage | 380v | 380v |
Power | 3.55kw | 4.55kw |
Dimension | 850*600*900mm | 850*600*980mm |
Weight | 120kg | 200kg |
3). Wood stick head screwing machine
This wood stick head screwing machine is used to cut screw thread shape on the wood round stick, then it can help the round wood stick fixed tightly on the mop.
Model Item | HTO-LWJ012 |
Power | 0.55kw |
Process diameter | 10-35mm |
Process length | 400mm |
Capacity | 650 sticks/h |
Machine dimension | 1000*850*950mm |
Machine weight | 80kg |
4). Axe handle polishing machine
This machine is used to polish the broom handleso that it will be very smooth and beautiful.
Model Item | HTO-PGJ005 |
Capacity | 360 sticks/h |
Power | 1.5kw |
Machine Dimension | 550*600*1150mm |
Motor speed | 3-12m/min |
3.Contact information for Cheapest Automatic Wood Axe Handle Machinery:
If you need further information, please contact us freely, we will do our best to cooperate with you.
