Automatic Wood Pallet Block Making Machine
1.Brief Introduction
This wood sawdust block making machine is used to make blocks/feet/log for pallets, which is can be used in packing industry and logistics.
1).Our wood sawdust block making line is mainly made up of Crusher, Dryer, Glue Mixing Machine, Press Machine and Saw to cut the block piece by piece.
2).The raw material for wood sawdust block making machine is sawdust, wood shavings, waste wood, used pallet and so on. If the raw material size is not very big we do not suggest crushing first.
3).The pallet block's size can be made by customer's demands.
2.Process of Producing
1).Crush wood branches, biomass, used pallets, wood logs, waste wood etc into powder, wood shavings or wood chips;
2).Dry the raw materials into certain moisture as 10%;
3).Mix materials with glue water;
4).Press materials into block shape as your demand size.
3.Technical parameters
Model |
HTO-MDJ150(Double Heads) |
HTO-MDJ100(Single Head) |
Specification of blocks |
Height: 75-145mm Width: 75-145mm |
|
Power |
20.3Kw |
13Kw |
Glue water amount used |
200-240kg/m3 |
100-120 kg/m3 |
Supports the density |
550-700kg/m3 |
|
Capacity |
4m3/24h |
2 m3/24h |
Warm prosecution type |
PID adjusts the merit accent to press the control |
|
Voltage |
380V 50Hz |
|
Weight |
1500kg |
1000Kg |
Dimension |
5000*700*1300mm |
5000*600*1300mm |
| ||
4.Contact information :
If you need further information, please contact us freely, we will do our best to cooperate with you.
