Widely Used Industrial Machine to Make Wood Chips

Widely Used Industrial Machine to Make Wood Chips photo-1
Widely Used Industrial Machine to Make Wood Chips photo-2
Widely Used Industrial Machine to Make Wood Chips photo-3
Widely Used Industrial Machine to Make Wood Chips photo-4
US$ 800 - 2,599 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Wood Chipper
Use:
on the specifications
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao or as customers' request
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Wood Chipper
Use on the specifications
Power Type Other, Electric,Diesel,PTO
Production Capacity 0.8-15t/h
Place of Origin Henan, China
Brand Name HENTO
Model Number HTO-XP400~1410
Dimension(L*W*H) on the specifications
Weight 200~2800
Certification ce
Warranty 2 years warranty
After-sales Service Provided Engineers available to service machinery overseas

Widely used Industrial Machine to Make Wood Chips



1. Brief Introduction of  Widely used Industrial Machine to Make Wood Chips

1).The  Machine to Make Wood Chips also named sawdust machine is a faster and more ideal and economical crushing equipment among

the crushers. Its finished shapes vary from sawdust, granular to flaky.



 2).Wood chipping machine is specially used to crush wood logs, bamboo, Wood staff and other wood materials. It can be processed

into wood chips once time. The wood chips size also can adjusted accordingly.



 3).Wood chipping machine can cut log and smalldiameter log with less than 200mm diameter and is applicable to paper pulp

factory, forest tree factory, paper mill, thermal power plant, etc.

2. Structure of  Widely used Industrial Machine to Make Wood Chips



Wood chipping machine is mainly composed of four parts such as principal machine, coupling, bottom frame and motor,

etc, in which the principal machine of chipping machine is composed of cutter head, upper and lower covers, feed inlet and

outlet, etc.

3.Technical Parameter of  Widely used Industrial Machine to Make Wood Chips

Item

Model

Capacity(t/h)

Power

Machine weight(kg)

rotating speed(r/min)

Dia. of Cutter(mm)

Quantity of cutter(alloy steel)

HTO-XP400

0.8-1

7.5-11KW

200

1500

450

4

HTO-XP500

1-1.5

11-15KW

320

1500

500

4

HTO-XP600

1.5-2

18.5-22KW

420

1500

600

4

HTO-XP800

3-6

22-30kw

550

480

800

4

HTO-XP1000

5-8

45kw

800

550

950

4

HTO-XP1100

6-9

45-55kw

1650

600

1100

4

HTO-XP1210

8-10

75kw

2100

600

1210

4

HTO-XP1410

10-15

90-120kw

2800

600

1410

4





Widely Used Industrial Machine to Make Wood ChipsWidely Used Industrial Machine to Make Wood ChipsWidely Used Industrial Machine to Make Wood ChipsWidely Used Industrial Machine to Make Wood Chips



4.Contact Information for  Widely used Industrial Machine to Make Wood Chips

If you need further information, please contact us freely, we will do our best to cooperate with you.
