Best Quality Steel Wire Drawing Machine
US$ 4,000 - 25,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Inlet Diameter:
2.8-16mm
Outlet Diameter:
0.5-5mm
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao or as customers' request
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Automatic Brick Making Machine For Sale In USAUS$ 3,500 - 7,500MOQ: 1 Set -
Automatic Laundry Folder Machine / Folder MachineUS$ 15,000 - 20,000MOQ: 1 Set
-
Automatic Paper Cup Making Machine Prices/Paper Cup Machine PricesUS$ 5,590 - 7,999MOQ: 1 Set
-
High Efficient Machine for Making IncenseUS$ 390 - 4,999MOQ: 1 Set
-
Paint Mixing Machine With Low PriceUS$ 5,899 - 6,999MOQ: 1 Set
Condition
New
Inlet Diameter
2.8-16mm
Outlet Diameter
0.5-5mm
Place of Origin
Henan, China
Brand Name
HENTO
Model Number
HTO-LSJ300
Voltage
380V(can be changed as customers' need)On the specification
Power(W)
22-55KW
Dimension(L*W*H)
on the specification
Weight
on the specification
Certification
CE,SGS,TUV
Warranty
Two years warranty period
After-sales Service Provided
Engineers available to service machinery overseas
Best Quality Steel Wire Drawing Machine
1.Technical parameters:
|
Model Item |
HTO-LSJ300 |
HTO-LSJ350 |
HTO-LSJ400 |
HTO-LSJ450 |
HTO-LSJ500 |
HTO-LSJ560 |
HTO-LSJ600 |
HTO-LSJ700 |
HTO-LSJ800 |
HTO-LSJ900 |
HTO-LSJ1200 |
Block diameter(mm) |
300 |
350 |
400 |
450 |
500 |
560 |
600 |
700 |
800 |
900 |
1200 |
Strength of inlet wire (MPa) |
≤1250 |
||||||||||
Number of Block |
2~11 |
2~11 |
2~11 |
2~12 |
2~12 |
2~12 |
2~12 |
2~9 |
2~9 |
2~9 |
2~9 |
Maximum diameter of inlet wire (mm) |
2.8 |
3.5 |
4.2 |
5 |
5.5 |
6.5 |
8 |
10 |
12.7 |
14 |
16 |
Minimum diameter of outlet wire (mm) |
0.5 |
0.6 |
0.75 |
1 |
1.2 |
1.4 |
1.6 |
2.2 |
2.6 |
3 |
5 |
Highest drawing speed (m/s) |
~25 |
~20 |
~20 |
~16 |
~15 |
~15 |
~12 |
~12 |
~8 |
~7 |
~6 |
Drawing power (kw) |
7.5~18.5 |
11~22 |
11~30 |
15~37 |
22~45 |
22~55 |
30~75 |
45~90 |
55~110 |
90~132 |
110~160 |
2.Contact information:
If you need further information, please contact us freely, we will do our best to cooperate with you.
