Band Knife Leather Splitting Machine / Leather Splitting Machine
1.Machine introduction of Leather Splitting Machine
1).This Leather Tannery Machine is used to split the hard and soft materials of wideness below 420mm and thickness below 8mm.
2) Leather Tannery Machine can arbitrarily adjust the thickness of splitting pieces to improve the quality of the products.
3 )This Leather Tannery Machine can show digital thickness of splitting pieces and infinitely change speed when feeding the materials.
4)Grinding knife adjusting device and automatic starting control equipment with the single handle.
5)With automatic locating device of feeding knife, no need to adjust cutting tool.
6)Automatically adjust the gap of pressure board and cutter to ensure more accurate splitting precision.
7)Automatic detection system of electronic phase.
8)The system which automatically stops when leather materials are entangled in.
9)The device that absorbs individual dust of leather and grinding knife.
10)The banding knife which is 3570mm long is durable and economic, which reduces the running cost.
11)The outsize makes the operation of knife more steady and accurate.
12)The accurate rail makes flywheel move more reliable and replacement of banding knife easier. , quicker and more convenient.
13)When splitting different leather, the splitting pressure can be adjusted automatically.
14)Appropriate working height can reduce the tiredness of workers during operation.
15)The mechanical parts are always lubricated
2.Technical parameters of Leather Splitting Machine
Model |
HTO-PPJ320 |
HTO-PPJ420 |
HTO-PPJ520 |
Working width(mm) |
320 |
420 |
520 |
Feeding speed(m/min) |
1-16 |
1-16 |
1-16 |
Motor power(KW) |
2.5 |
2.77 |
2.77 |
Max splitting thickness(mm) |
8 |
8 |
8 |
Min splitting thickness(mm) |
0.15 |
0.15 |
0.15 |
weight(Kg) |
620 |
800 |
850 |
Overall dimension(L*W*H) |
1490*840*1200mm |
1590*840*1240mm |
1690*840*1240mm |
3.Contact information for Leather Splitting Machine:
If you need further information, please contact us freely, we will do our best to cooperate with you.
