Automatic Plastic Cup Making Machine Price
1.Machine introduction of Machine For Making Disposable Cup
Usage of Machine For Making Disposable Cup
Our High Quality Machine For Making Disposable Cup is mainly use PP/PS/PET/PVC/PLA, etc sheet to produce plastic kinds of disposable plastic products, such as plastic cups, cold/hot drinking cup, ice-cream cup, yoghurt cup, jelly cup, coffee cup, etc. It can make some regular shape products, such as plate, bowl, cover, dish, box with different moulds.
II. Main Features of Machine For Making Disposable Cup
1) The stretching of plugs inside of the upper mould are controlled by air cylinder.
2) The sheet feeding is driven by pin chain. The pin chain is controlled by motor with inverter and the feeding length can be set through touch screen.
3) It adopts two pillars to fix the mould. We could adopt four pillars to fix the mould.4) The up mould is fixed and the down mould movement is driven by twin cam. 5) There are total 16 heating zones. The temperature of each zone is controlled by Temperature control module.
6) The production process include sheet feeding, heating, plugs stretching, forming and in-mould cutting and blow final products out.
7) We adopt square steel to make the machine frame stronger.
8) The working performance of this machine is controlled PLC and touch screen.
Plastic cup making line
2.Technical parameters of Machine For Making Disposable Cup
Model |
HTO-PCM660C |
Mould Driving Method |
Cam |
Approximate Max. Forming Area |
660 x 300 mm |
Approx. Running Speed |
15-35 Stroke / min approx. during production |
Approx. Sheet width for feeding |
500 – 660 mm in rolls. |
Mode of cutting arrangement. |
In mould automatic |
Sheet thickness Range |
0.20 – 2.0 mm |
Material |
PP, PS, PET, PVC,PLA |
Max. Draw depth, (i.e. cup length) |
160 mm (Could be special design) |
Oil Pump Motor Power |
11KW |
Sheet Feeding Motor |
2.2KW |
Max. Sheet roll diameter. |
800 mm |
Heating arrangement |
Top + bottom heating with IR Ceramic Heater(120pieces, 650W) |
Temperature Controller & Thermocouple. |
PID K-Type |
Type of Mould |
Multi cavity 1 – 3 row. |
Approx. Electrical Consumption |
45KW/hr |
Approximate Dimension |
L3150×W1500×H2500 (mm) |
Approximate Weight |
4500Kg |
3.Contact information for Machine For Making Disposable Cup
If you need further information, please contact us freely, we will do our best to cooperate with you.
