Vortex Mixer

Name: Vortex Mixer
Brand: Scientz
SKU: 140474138
Availability: InStock

US$ 100 - 110 MOQ: 1 Piece

Key Specifications

Brand Name:

Scientz

Model Number:

sc-20120222002

Place of Origin:

Zhejiang, China

Ningbo Scientz Biotechnology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

NingBo

Delivery Detail:

Delivery time depends on order quantity.

Brand Name Scientz

Model Number sc-20120222002

Place of Origin Zhejiang, China

Specifications

Adjustable and Fixed speed Vortex Mixer
Suitable for touch or continuous operation
Sturdy cast casing
Eccentric with oille

Vortex mixers can be used to mix liquid with liquid, liquid with solid and powder and power(solid) quickly and evenly.

Vortex Mixer(Adjustable and Fixed speed Models)

Features

New vortex mixer suitable for touch or continuous operation
MX-S with wide speed range: 0-2500rpm, stepless speed regulation of motor
MX-S can be used for various shaking application with optional adapters for Eppendorf etc
Adapters securely clicked onto appliance in any position
Sturdy cast casing
Specially designed silicone feet and steel base for excellent vibration damping
Eccentric with oilless ball bearings

Specifications

	MX-S	MX-F
Voltage[VAC]	110-120/220-240	110-120/220-240
Frequency[Hz]	50/60	50/60
Power[W]	60	60
Shaking movement	Orbital	Orbital
Orbital diameter[mm]	4	4
Motor rating input[W]	58	58
Motor rating output[W]	10	10
Permissible on time[%]	30	30
Speed range[rpm]	0-2500	2500
Speed display	Analog Scale	-----
Run type	Continuous/touch operation	Continuous/touch operation
Dimensions[W×H×D mm]	127×130×160	127×130×160
Weight[kg]	3.5	3.5
Permissible ambient temperature[°C]	5-40	5-40
Permissible relative humidity	80%	80%
Protection class acc. DIN EN60529	IP21	IP21

Accessories
Cat No.	P/N	Description
18900034	VT1.1	Standard top,for <Ø30 mm tubes and small vessels
18900044	VT1.2	Tube holding rod, use with VTI.3.1 to VTI.3.5
18900035	VT1.3	Universal top plate,100mm plate attachment with 4 pcs vacuum suction feet
18900020	VT1.3.1	Tube adapter, for 48 holes test tubes Ø6mm, use with VT1.3 or VT 1.2
18900021	VT1.3.2	Tube adapter, for 18 holes test tubes Ø10mm, use with VT1.3 or VT1.2
18900022	VT1.3.3	Tube adapter, for 12 holes test tubes Ø12mm , use with VT1.3 or VT1.2
18900023	VT1.3.4	Tube adapter, for 8 holes test tubes Ø16mm, use with VT1.3 or VT1.2
18900024	VT1.3.5	Tube adapter, for 8 holes test tubes Ø20mm, use with VT1.3 or VT1.2
