Specifications
juice bottle overturn sterilizer
1.capacity: 8000-12000bph
2.sterilizing time:30-45S
3.chain speed:4.5-25m/minute
juice bottle overturn sterilizer
Machine introduction:
This machine is mainly used on fruit juice or tea drink hot bottling lines. It could overturn bottles(glass bottle or PET bottle), which have been filled and sealed, to sterilize inside of bottle month and caps by high temperature drink in bottle. Chain conveyor overturns finished bottles from upright to horizon when sterilizing cap and bottle mouth. And the anna conveyor transfers bottles into cooling tunnel.
Features: top grade of conveying chain is used on the machine, more stable and reliable when it is working, don't break bottles. Speed of conveying system is infinitely variable.
Machine parameter:
| Model: | SRD-100 | SRD-200 | SRD-300 |
| Capacity: | 4,000-6,000bph | 8,000-12,000bph | 12,000-18,000bph |
| Application range: | plastic bottles, glass bottles, roof-like package | ||
| Sterilizing time: | 30-45s | ||
| Chain speed: | 4.5-25m/min | ||
| Motor power: | 1.5KW | 1.5KW | 2.2KW |
| Outer dimension | 7350X731X1120MM | 8350X731X1120mm | 10350X731X1120mm |
Our product juice bottle overturn sterilizer, which is widely used in beverage plant.
Send us pictures of your bottles and caps, right machine will be recommended to you.
Contact us for more details including price!
Welcome to visit our workshop!
