BY-LOX Digital Thermostat for Reptile Aquarium Incubator Heat Mat Lamp

BY-LOX  Digital Thermostat for Reptile Aquarium Incubator Heat Mat Lamp

Feature:

• Color: White

• Dimensions: 120 x 63 x 32 mm (approximate)

• Probe line length: 2450 mm

• Rated voltage: 220-240 V AC

• Controllable temperature range: -9 to +38 degree

• Maximum load power:2000 W

Operating instruction:

• Switch on the thermostat with power, the screen shows current temperature

• Button "SETTING": used for switch between "WORKING" mode and "SETTING" mode. Press once, the thermostat go into setting mode, press another, the thermostat goes back to working mode.

• Button "TEMPERATURE +": used for elevating temperature. When the screen shows "SETTING", each pressing on the button elevates 1 degree. Long pressing on increases the temperature till +38 degree. After 5 seconds no operating, the thermostat returns to working mode.

• Button "TEMPERATURE -": used for lowering temperature. When the screen shows "SETTING", each pressing on the button reduce 1degree . Long pressing on lowers the temperature till -9 degree. After 5 seconds no operating, the thermostat returns to working mode.

Heating mode and cooling mode :

• In the "WORKING" mode, press Button "TEMPERATURE +", after 4 seconds, the "WORK" mode will change, heating mode to cooling mode, or cooling mode to heating mode.

• Heating mode (red light bright):

• When current temperature set temperature - 1degree ,switch on the power.

• When current temperature set temperature + 1degree ,cut off the power.

• Cooling mode (green light bright):

• When current temperature set temperature + 1degree ,switch on the power.

• When current temperature set temperature - 1degree ,cut off the power.

• Protection function: When short circuit occurs, temperature screen shows [dd], the power automatically cut off.
