slat floor for pigs/frp pultrusion beams/Fiberglass Beams Support For Pig Floor
Pultrusion process
During the pultrusion process, the raw material are pulled through a heated steel forming
die using a continuous pulling device. when the reinforcements are saturated with the
resin mixture in the resin bath and the wetted reinforcement package is wrapped in a
surfacing veil. the completed package then goes into premolding stage that roughly forms
the package into the appropriate shape to enter the heated trimming die for curing. the
trimming die is the exact shape of the final part desired. upon exiting the trimming die,
the part is over 90% processing and solid. Cutting in accordance with requirements of the
length, the entire process is completed.
Frp Product Main Raw Material
1 .Reinforcement material: fiberglass, continuous strand mat.
2. Basis material: unsaturated polyester resin, epoxy resin, vinylester resin.
Features
1,Corrosion resistance: no influence of water quality FRP pipe can resist acid, alkali, salt, water, untreated sewage, corrosive soil or underground water and many chemical fluid of erosion
2, Light weight,high strength and easy to cutting and installation.
3,Good Thermal Aging Resistance: service life is in commonly 20 years of above
4,Insulated , fire-resisting and nonmagnetic.
5,Slip Resistance and fatigue resistance.
6,The color of inner and outer parts is same and the color can be arbitrary selecti
Widely used for chicken/poultry farm, pig farm.
specifications
| No. | Type | specification/mm | Weight(kg/m) | FOB(RMB/m) |
| 1 | Hollow 200 | 200*30*5.5 | 2.7 | 50 |
| 2 | Hollow135 | 135*30*5.5 | 1.7 | 30 |
| 3 | Hollow120 | 120*30*5.5 | 1.52 | 26 |
| 4 | Reinforced hollow 120 | 120*30*5.5 | 2.36 | 40 |
| 5 | Hollow100 | 100*30*5.5 | 1.35 | 23 |
| 6 | Hollow80 | 80*30*5.5 | 1.1 | 21 |
| 7 | trapezoid100 | 100*50*5.5 | 1.4 | 35 |
| 8 | triangle150 | 150*45*5.5 | 32 | |
| 9 | triangle135 | 135*45*5.5 | 1.45 | 30 |
| 10 | triangle120 | 120*45*5.5 | 1.3 | 25 |
| 11 | triangle100 | 100*45*5.5 | 1.2 | 22 |
| 12 | Solid 126 | 126*25.4*5.5 | 1.3 | 23 |
| 13 | Solid 120 | 120*25.4*5.5 | 1.33 | 25 |
| 14 | Solid 114 | 114*40*7 | 40 | |
| 15 | Solid 100 | 100*25.4*5.5 | 1.05 | 21 |
| 16 | Solid 60 | 60*25.4*5.5 | 0.78 | 17 |
| 17 | Composite beam 100 | 100*50 | 42 |
Company was founded in 1993, its predecessor is a joint venture company, through optimization and enterprise restructuring become Qingyun Maoshengyuan Composite Material Co. We have over 20 year' experience of producing frp farm equipment. We own wellequipped testing equipment and strong technical force. With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in farms and others. Our company has been grown into one of the best manufacturers in the production of FRP pultrusion structural sections. Beyond domestic market.
