Home > Metallurgy, Mineral & Energy > Steel & Products > Steel Sheet & Plate > Price Onduline Heat Resistant Steel Profile

Price Onduline Heat Resistant Steel Profile

Name: Price Onduline Heat Resistant Steel Profile
Brand: wzh group
SKU: 140424998
Availability: InStock

US$ 2 - 5 MOQ: 25 Tons

Key Specifications

Get Latest Price

Standard:

AISI, ASTM, DIN, GB, JIS

Grade:

steel

Thickness:

0.14-1.2

Contact Supplier Request Quote Chat Now

Hebei Weimeng Import & Export Trade Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

xingng

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Standard AISI, ASTM, DIN, GB, JIS

Grade steel

Thickness 0.14-1.2

Brand Name wzh group

Model Number as request

Type Steel Plate

Technique Cold Rolled

Surface Treatment Galvanized

Application Boiler Plate

Special Use High-strength Steel Plate

Width 750-1250, 828/840/750/950/1050/910/960/980/910/750/900

Length 1m/ 3m/5m, 3m/ 5m

Specifications

High quality, beautiful appearance
easy assembling, good fonction
loww cost, long live using
waterproof, fireproof,antirust

Introduce

Corrugated sheets are made from Galvanized steel coils, Galvalume Steel coils, Galvalume Pre-painted sheet and aluminum sheet, pre painted hot dip galvanized steel coils, roll formed by roll forming machines, the thickness and color can be different, these panels are featured with easy installation, high strength and low in lost. They are widely use as the wall or roof of factory, warehouse, garage, exhibition center, cinema etc.

From: steel coil/ pre-painted steel coil

Specification

1. Model No.: YX25-210-840, YX12-65-850, YX40-320-960, YX750, YX25-207-828, YX25-210-840, etc.

2. Material: Pre-painted galvanized sheets, prepainted galvalume steel sheets
Coating: PE

3. Sheet Thickness: 0.23-0.60mm
4. Sheet Peak Height: 40mm
5. Sheet Peak Spacing: 320mm
6. Width: 960mm

7. Zinc coating: 30-120g/sqm
8. Length: any length, according to the transportation, generally less than 12m
9. Standard color: red, blue, white grey
Special color: according to RAL color
10. Packing: Plastic film, pallet or as your requests
11. Certificate: ISO9001

Advantage

1. Light weight

2. Elegant and long-life : Manifold disquisition and oversea used approving more than 40 years; Through especial coated dispose, the color coated steel panel's guaranty is 10-15 years, and the panel's life express 35 years by painting the antisepsis material after each 10 years

3. Pressing steel panel with the clear line, and many colors for choice, suitable for any different building style materials , achieving satisfying effects

4. Pressing steel panel can be freely incised, it can satisfy the especially designing demand

Usage

It is hot rolled into the required profiles from preprinted galvanized steel sheets , which is used as roofing panel in all kinds of buildings, such as industrial and civil buildings, warehouse, particular building, inner and outer decorative wall. It can be used in ceiling tiles, steel structure workshop, sandwich panel workshop, transportation, outside decoration of various buildings, home appliances like refrigerator, air conditioner, electric cookware, etc.

Quality:

1. Import processing equipment, modernized production line

2. Reasonable and strict processing flow.

3. Strict quality inspection five inspection procedures

Service

1. Free technique consulting, project design.

2. Commitment of many years quality assurance.

Goods name	Color corrugated steel sheet
Brand	weizhengheng
Plance of origin	Hebei
Quality	Prime quality
Certificate	ISO9001
Thickness	0.14-0.7mm
Width	600-1005mm
Length	As costomer’s requirements
Grade	SGCC/DX51D/SGCH
Zinc	60-120g/m2
Color	As customers' request
Galvanized	Coated
Material	Steel
Ensure we can supply customers' with different specifications of the highest quality and lowest price. Sincerely welcome to contact us for the future details if any item interest you ,and we will make every effort to assure that your requirements will be satisfied ,and we hope to establish long-term business relations with you on the basis of the equality and mutual benefit. we are waiting for your email.
