ASTM A 653 Grade 50/80 Z & C PURLINS STEEL

Specifications

PRIME HOT ROLLED MILD STEEL H BEAM Z purlin C purlin
SIZE: Differentes sizes
STEEL GRADE: SS400 Q235 S23

ASTM A 653 Grade 50/80 Z & C PURLINS  STEEL





H channel/ H beam/ C purlin/ Z purlin



Features:
1) Manufactured from high tensile galvanized steel
2) Despotic C&Z section steel, Z section steel is roll-formed from galvanized steel, specification to be complete
3) Make from quality raw material
4) Pre-punched holes based on detail design
5) Complete accessories package available
6) C purlin, Z purlin and H beam are widely used in factory buildings, large-span bridges, gymnasiums and portable houses
7) C purlin may be used in single spans and continuous spans in multi-bay buildings
8) We can make adjustment to meet your inquiries as we can do







H channel description:

PRIME HOT ROLLED MILD STEEL H BEAM
SIZE: Differentes sizes as require of the steel frame
STEEL GRADE: SS400 Q235 S235JR

H  beam Usages:

1. Steel structure workshop;

2. Steel web frame structure;

3. Steel H-column and steel H-beam;

4. Portal frame products;

5. High rise building project;

6. Others steel structure buildings.







Workflow:

Manual decoiling----feeding and guiding----levelling----punching----roll forming----straightening----cut to length----run out table







Details informations of H beam

General Product Information
Commodity	Hot rolled H beam
Material Grade	SS400,Q235B,Q345B,S235JR
High&width	100-900mm
Thickness	6-40mm
Length	5.8m or customered
Application	Industrial structure beams and columns:
	1). Steel bearing bracket of the industrial structures
	2). Steel piles and supporting structure of underground works
	3). Industry equipment structure like petrochemical and power
	4). Large-span steel bridge components
Further treament	Galvanized etc



 Detailed specifications of different H chanels:









C Purlin

Galvanized C Purlin:
1. Specialized manufacturer and exporter
2. UL, cUL, CE, IEC, TUV and SGS certificates
3. ISO9001-2008

Material C purlin:
Q235B Steel (Chinese standard steel), SS304, SS316 & SS316L



Surface Finish C purlin:
Electro zinc plated – for indoor use to BS EN 12329-2000

Powder coated - for indoor use to JG/T3045-1998, between 6 and 10 microns thick

Hot Dipped Galvanized – for outdoor use to BS EN 1461-1999, between 60 and 80 microns thick

Electrolytic Polishing – for stainless steel use



Galvanized C Purlin Specifications:

 100*41mmx62mm

 150*41mmx82mm

 210*41mmx41mm

 500*41mmx21mm

 and many other specifications customized



Different C beams:



Advantage of Galvanized C Purlin :

1.High quality

2.Reasonable price

nvenient in construction and save much time and labor

4.light, good quality and reasonable price

5.length of the product can be manufactured according to customers requirments

8.high mechanical strength, back to back C channel, increase the intensity.



Specifications of Z purlin



Z Type Steel purlin
1.Thickness:0.5mm to 4mm.
2.Grade:Q235,Q345.
3.Width:80mm to 300mm.
4.Material:Galvanized/prepaint/black



For more informations, please contact with me
