automatic PLC Johnson filter screen mesh welding equipments made in China from Jiake Factory
- 45 Set / Sets per Month
- xingang
- T/T
Product Details
Condition: | New | Place of Origin: | Hebei, China | Brand Name: | JIAKE |
Model Number: | JK 50-200MM | Arc Current: | 12 | Pulse Frequency: | 11 |
Pilot Arc Current: | 12 | Rated Duty Cycle: | 11 | Motor Type: | AC Motor |
Dimensions: | 13000*1500*3300mm | Usage: | screen mesh, filter mesh | Voltage: | 380V 50Hz |
Power(W): | 380V 50Hz | Certification: | ce | Warranty: | one year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Contact:Miss Daisy
Skype:qq1815361000
Wechat/whatsapp/mobile:+86 15324391556
Fax:+86 0318- 7565522
Hebei Jiake Welding Equipment Co.,LTD
Address:Wire Mesh Industrial Zone, Anping County, Hebei Province, China
Filter Mesh Welding Machine
Fiter Mesh Welding Machine Usage: welding wire wrapped screen pipe, mineral filtrating mesh, coal washing mesh, waterfiltration mesh, water well screen etc.
Filter Mesh Welding Machine function and parameters:
Machine’s work mode: Automatic and Adjustable
a). Automatic mode, input correct variable value then the machine can work automatic cycle.
b). Adjustable mode, every parts movement of machine could be adjustable, like a manual mode.
Technical Parameters:
Model | 50—200mm | 100—600mm | 600—1200mm |
Power | 3Phase 380V 50Hz | 3Phase 380V 50Hz | 3Phase 380V 50Hz |
Rated capacity | 100KVA | 100KVA | 100KVA |
Slot distance | ≥0.1mm | ≥0.2mm | ≥0.25mm |
Canister length | Max 6000mm | Max 6000mm | Max 4000mm |
Weld material | Stainless steel wire & Low carbon steel wire | ||
V-wire size | 1.8—5.0mm | 1.8—5.0mm | 1.8—5.0mm |
Support rod size | 1.8—5.0mm | 1.8—5.0mm | 1.8—5.0mm |
Overall dimension | 13000*1500*3300mm | 13000*1600*3400mm | 11000*2100*3800mm |
Weight | 10000KG | 11000KG | 13000KG |
Slot size: ≥0.25mm canister, diameter should be within 30-400mm
≥0.7mm sieve, diameter should be within 400-600mm
≥1mm sieve, diameter should be within 600~1200mm
filtermesh welding machine have the strongpoint of low noise, low energy consumption and stable function. The electrical control system is researched and developed by ourselves, main axis and feeding axis are both adopt Panasonic Brand AC power servo motor and drivers. Slot size adopt NC servo motor to drive ball-screws, ball-screws drive the drawing support rods plate sliding on linear guideway according to the instructions, slot size could be adjusted randomly.
Accessorial Parts:
Vshaped wire machine; wire rolling machine; straightening&cutting machine; electric control cabinet; flatter mesh machine; cutting mesh machine
Note: Two motors, one for drawing mesh 2kw, one for rolling the mould 3kw
After-sale service:
1.We offer installation and train the workers for the customers.
2.Guarantee time:one year since the machine was installed at buyer's factory but within 18 months against B/L date.
3. We can help design the layout of the machine placed in the factory.
Hebe Jiake Welding Equipment Co.,Ltd mainly produce reinforcing mesh welding machine, fence mesh welding machine, construction mesh welding machine, chicken cage mesh welding machine, 3D panel production line, filter mesh welding machine, steel bar cage making machine, chain link fence machine, gabion mesh machine, nail making machine, barbed wire machine, welded wire mesh machine, razer barbed wire machine, steel grating mesh welding machine, fence mesh weaving machine, stainless steel wire mesh weaving machine and so on.
