wedged wire screen welding machines for coal washing mesh
- 10 Set / Sets per Month
- xingang
You May Like
-
Johnson pipe screen mesh welding machines for drilling well
-
Johnson water well screen pipe welding machines made in China
-
low carbon steel wire Johnson pipe screen mesh welding machines
-
Johnson pipe screen mesh welding machines for water well casting screen pipe
-
stainless steel Johnson pipe screen mesh welding machines for drilling well
-
automatic PLC Johnson pipe mesh welding equipments made in China from Jiake Factory
Product Details
Condition | New | Place of Origin | Hebei, China | |
Brand Name | JIAKE | Model Number | JK | |
Arc Current | 10 | Pulse Frequency | 2 | |
Pilot Arc Current | 10 | Rated Duty Cycle | 10 | |
Motor Type | AC Motor | Dimensions | 13m*1.5m*3.3m | |
Usage | for mineral filtrating mesh | Voltage | 380V or as required | |
Power(W) | 3KW | Certification | CE | |
Warranty | one year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
wedged wire screen welding machines for coal washing mesh
wedge wire screen diameter | 100-400mm |
wedge wire screen length | max.6000mm |
suitable wire | stainless steel wire, or carbon steel wire, wire daimeter 2.0-5.0mm |
slot(aperture)/space between welding lines | 0.2-16mm |
welding precision | if wire diameter tolerance is within 0.01mm, welding precision will be within =/-0.04mm |
welding speed | 6-30rpm adjustable based on tube diameter |
welding transformer power | AC 100KW |
driving motor power | servo motor(one 3KW and one 2KW and one 1.5KW) |
welding material | stainless steel wire and low carbon steel wire |
voltage | 3 pahse, 380V, 50HZ or according to customer's requirement |
dimension | 13m*1.5m*3.3m |
weight | 10T |
The wedged wire screen welding machines is intended for manufacturing of wedge wire screens in length up to max.6000mm. the strength, precision, and design flexibility that characterize our screens makes them the choice a broad range of industries
and applications. it made up of CNC mainframe, welding transformer, control cabinet and so on.
wire coiling machine V wire rolling machine
A: Pre-sale service; plant layout design, technical consulting, feasibility studies, cost and ROI analysis;
B: sales services: installation and commissioning, operator training, electrician and mechanic training;
1.Equipment installation and commissioning: assist and guide customer coordinate the equipment layout according to the actual situation, make reasonable arrangements for the overall planing of the installation location. Assigned technician to provide equipment installation, operation, ancillary facilities, production, repair, maintenance services and answer the relevant questions.
2.Training operation and maintenance personnel: our company will provide training of the operation and maintenance personnel according to customer’s requirement.
C: after-sale service; supply spare parts and provide after-sale services
1.supply of spare parts: keep records for each customer, provide long-term supply of spare parts, and send it to customers hand with the fastest speed according to customers’ requirement.
2.Unexpected emergency repair service: once the equipment have malfunction, and the user unable to rule out, we will arrange technician to the user factory in the soonest time, solve the trouble and resume production in time.
Inquire now,and we will reply ASAP. Welcome to visit our factory
