automatic griddle mesh welding machine factory
griddle filter mesh welding machine
a.Main parameter:
Model |
Φ50-200mm |
Φ100-400mm |
Φ400-1200mm |
Power |
380V 3 phase 50Hz |
380V 3 phase 50Hz |
380V 3 phase 50Hz |
Rated capacity |
100KVA |
100KVA |
100KVA |
Slot distance |
min 0.1mm |
Min0.2mm |
Min 0.25mm |
Canister length |
Max 6000mm |
Max 6000mm |
Max 4000mm |
Weld material |
Stainless steel wire& low carbon steel wire |
||
V-wire size |
0.8-3.0mm |
1.8-5.0mm |
1.8-5.0mm |
Support rod size |
0.8-3.0mm |
1.8-5.0mm |
1.8-5.0mm |
Overall dimension |
13000*1500*3300mm |
13000*1600*3400 |
11000*2100*3800mm |
weight |
10T |
11T |
13T |
b.Main features:
welding wire wrapped screen pipe, mineral filtrating mesh, coal washing mesh, water filtration mesh, water well screen etc.
Machine’s work mode: Automatic and Adjustable
a). Automatic mode, input correct variable value then the machine can work automatic cycle.
b). Adjustable mode, every parts movement of machine could be adjustable, like a manual mode.
We also provide griddle mesh welding machine
1. Reinforcing Mesh Welding Machines
|
wire diameter: 5-12mm mesh width: max2.5m wire spacing: 100-300mm mesh length: max12m welding speed: 30-60 cross wires/min |
|
|
2. Fence Mesh Welding Machines
|
wire diameter:3-6mm mesh width:max 2.5m wire spacing:50-200mm welding speed: 45-75 cross wires/min |
|
|
3. Concrete Reinforcing Mesh Welding Machines
|
wire diameter:3-8mm mesh width: max2.5m wire spacing 100-300mm welding speed:45-75 cross wires/min |
|
|
4.Poultry Cage Mesh Welding Machines
|
wire diameter 1.8-3.5mm mesh width:1.2m wire spacing: 50-200mm welding speed:60-90cross wires/min |
|
|
5. Electric Welded Mesh Machines
|
wire diameter:0.45-0.85mm wire diameter:0.6-1.3mm wire diameter:0.8-1.6mm wire diameter:1.4-2.7mm mesh width: as required wire spacing: as required |
|
|
Our company has a sound service system, from customer requirements gathering, pre-sales technical consulting, installation and commissioning in sales, and after sales maintenance of equipment. All of service system only for your satisfaction.
A: Pre-sale service; plant layout design, technical consulting, feasibility studies, cost and ROI analysis;
B: sales services: installation and commissioning, operator training, electrician and mechanic training;
1.Equipment installation and commissioning: assist and guide customer coordinate the equipment layout according to the actual situation, make reasonable arrangements for the overall planing of the installation location. Assigned technician to provide equipment installation, operation, ancillary facilities, production, repair, maintenance services and answer the relevant questions.
2.Training operation and maintenance personnel: our company will provide training of the operation and maintenance personnel according to customer’s requirement.
C: after-sale service; supply spare parts and provide after-sale services
1.supply of spare parts: keep records for each customer, provide long-term supply of spare parts, and send it to customers hand with the fastest speed according to customers’ requirement.
2.Unexpected emergency repair service: once the equipment have malfunction, and the user unable to rule out, we will arrange technician to the user factory in the soonest time, solve the trouble and resume production in time.
Tell us your need, we will surprise you with best price, best quality and best service!
We can customize the machine, please tell us your needs.
