Steel grating piezoresistive welding machine
Steel doses of board weld production line to finish flat-rolled steel and round steel (is it entangle square steel to sprain ) horizontal to weld automatic production line of shaping alternately while being vertical, the products can reach hundreds of kinds of specifications , apply to the platforms of such trades as petroleum , chemical industry , electricity , quay , municipal administration , environmental protection , national defence ,etc. , hang and carry , enclose the bar , walk etc. extensively.
24 meters long, 3.8 meters wide production line this, divide into person , welder person , cut according to process worker of end head person , finished product deposit engineering location, worker of material loading,. Material loading adopt artificial material loading (flat-rolled steel ), horizontal pole (round steel ) hands over the material automatically , then weld automatically, walk into automatically, is it cut location , worker of material , cut end head automatically , artificial to operate with draw material car hand over the finished product to the depositing area of the finished product to reach, then one is put automatically , pile up the platform to drop automatically , is full of until piling up the platform, operate and introduce the car artificially and put out the finished product one.
Main technical data:
Input power | 3 phase 380V 50Hz |
Specified input power | 1600KVA |
Amount weld electric current | 200KA |
Most largely weld electric current | 350KA |
Flat bar steel width | 20-75mm |
Flat bar steel thickness | 2.5-7.0mm |
Horizontal pole(cross bar) diameter | 4,5,6,8mm |
Welding length | 6000mm |
Max. welding width | 1000mm |
Pitch of flat bar steel | 30mm, 40mm,50mm, 60mm (min. 25mm) |
Pitch of cross bar | 50mm, 100mm (from 38mm to 160mm) |
Welding speed | 15-25 times/minute (welding row by row) |
