high speed welded mesh machine
high speed welded mesh machine
welded wire mesh machine
high speed welded mesh machine
1. welded wire mesh machine
Welded wire mesh machine is used to produce welded wire mesh of various sizes by welding galvanized iron wire or iron wire or together.
2.welded wire mesh characteristic:
high stability, lowness noise, draws straight and sends wire automatically. It can weld the wire mesh which has thick diameter.
It has the board machine frame, electromagnetism stepless time, the distance of wire is wide, small noise, stabilization and save electricity, the mesh is standard. The machine can be used to weld low carbon steel wire, stainless steel wire mesh and other kinds of welded wire mesh.
3.welded wire mesh machine main parameter:
|
Diameter (mm) |
Welding aperture (min) |
Width of mesh (max)m |
Welding transformer |
Welding head (mm) |
Welding speed (time/min) |
Input the power (adjustable) |
Weight (t)
|
0.4-0.65 |
1/4*1/4’’ |
1.2 |
30*4 |
9 |
120-160 |
380v 50hz 3phase |
1.5 |
0.4-0.8 |
1/2*1/2’’ |
1.2 |
30*4 |
9 |
120-160 |
380v 50hz 3phase |
1.5 |
0.8-1.2 |
1/2*1/2’’ |
1.2 |
56*4 |
12 |
80-120 |
380v 50hz 3phase |
2 |
1.2-1.8 |
1*1’’ |
1.2 |
56*4 |
12 |
80-120 |
380v 50hz 3phase |
2 |
≥1.8 |
2*2’’ |
1.2 |
70*4 |
16 |
80-120 |
380v 50hz 3phase |
2 |
packing & loaing container
