Gabion Mesh Machine
Gabion mesh machine is also called heavy type hexagonal mesh machine, it adopt PLC automatic control,
it has the characteristics of moving stead low noise, high potency, it is ideal machine for weaving
hexagonal wire mesh with big specifications, big width, and big diameter.
Gabion purposes: (a) control and guide of water or flood (2) spillway dam and diversion dam (3) rock fall
protection (4) to prevent water erosion (5) Bridge protection (6) solid soil structure (7) coastal defense works
(8) port Project (9) retaining wall (10) road protection
Gabion Mesh Machine Main Parameters:
Model | Mesh size (mm) | Max width (mm) | Wire dia (mm) | Twisted No. | Main axis speed (r/min) | Power (KW) | Theoretical speed (m/h) |
LNWL23-60-2 | 60*80 | 2300 | 1.6-3.0 | 3 | 25 | 11 | 165 |
LNWL23-80-2 | 80*100 | 1.6-3.0 | 195 | ||||
LNWL23-100-2 | 100*120 | 1.6-3.2 | 225 | ||||
LNWL23-1200-2 | 120*150 | 1.6-3.5 | 20 | 255 | |||
LNWL33-60-2 | 60*80 | 3300 | 1.6-2.8 | 25 | 15 | 165 | |
LNWL33-80-2 | 80*100 | 1.6-3.0 | 195 | ||||
LNWL33-100-2 | 100*120 | 1.6-3.2 | 225 | ||||
LNWL33-120-2 | 120*150 | 1.6-3.5 | 20 | 255 | |||
LNWL43-60-2 | 60*80 | 4300 | 1.6-2.8 | 25 | 22 | 165 | |
LNWL43-80-2 | 80*100 | 1.6-3.0 | 195 | ||||
LNWL43-100-2 | 100*120 | 1.6-3.0 | 225 | ||||
LNWL43-120-2 | 120*150 | 1.6-3.2 | 20 | 255 | |||
LNWL43-60-3 | 60*80 | 4300 | 1.6-2.8 | 5 | 25 | 22 | 165 |
LNWL43-80-3 | 80*100 | 1.6-3.0 | 195 | ||||
LNWL43-100-3 | 100*120 | 1.6-3.0 | 225 | ||||
LNWL43-120-3 | 120*150 | 1.6-3.2 | 20 | 255 |
| CS-A TYPE BARBED WIRE MACHINE | | |
| RAZOR BARBED WIRE MACHINES | | |
| FENCE MESH WELDING MACHINE | | |
| CHAIN LINK FENCE MACHINE | | |
| GRASSLAND FENCE MACHINE | | |
We can customize the machine, please tell us your needs.
Contact: Daisy Lee
Hebei Jiake Welding Equipment Co.,Ltd
Mobile: :+86-318-15324391556
Fax:+86-0318-7565522
Skype:qq1815361000
Send Inquiry to This Supplier
