China Wire mesh fence welding equipment
China Wire mesh fence welding equipment
China Wire mesh fence welding equipment
China Wire mesh fence welding equipment characteristics:
This machine adopts synchronous control technique, both welding time and separate-control welding is controlled by PLC, input panel has been divided into two kind, they are touch screen and button. This made the operation more intelligent and rationalization. This machine use electric as its motive power, and it use the step motor hopper, brake motor drive the car to put the weft. And drawing mesh use the step motor. The longitudinal and weft should be pre-cut. The biggest advantage is that can produce different aperture in both longitudinal and weft.
China Wire mesh fence welding equipment main parameter:
Diameter |
Welding aperture |
Width of mesh |
Length of mesh |
Welding head |
Welding transformer |
Welding speed |
weight |
2.5-4mm |
50*50mm |
≤2.5m |
≤6m |
48*20mm |
85kva*6 |
35times/min |
4t |
4-6mm |
100*100mm |
≤2.5m |
≤6m |
24*20mm |
85kva*6 |
35times/min |
4t |
China Wire mesh fence welding equipment
