Help CenterProfessional Prefabricated Garage House With Low Cost
Related Products
-
Mini Modular HomesUS$ 30 - 70MOQ: 200 Square Meters -
Rockwool Sandwich Panel for Roof&wallUS$ 7 - 30MOQ: 600 Square Meters
-
Steel Welded Fence, Metal Part. Steel Fabricate,punching & StampingUS$ 800 - 1,800MOQ: 16 Tons
-
Color Coated pu Sandwich Panel RoofingUS$ 18 - 48MOQ: 600 Square Meters
-
Light and Insulation Eps Sandwich PanelUS$ 5 - 20MOQ: 600 Square Meters
Specifications
professional prefabricated garage house with low cost1. flat packing
2. easily assembled
3. low cost and carbon
1. Brief Introduction
It is a kind of light steel structure prefab house with the EPS color steel sandwich panel, rock wool, PU for the insulation. It can maximize customer require and satisfaction for the cost and quality. All the house parts are knock-down as flat package before loading container. We can provide the service of installation, supervision and training by extra.
2. Specification Info.
| Component | Material |
Ground Beam |
8# C steel |
Ring Beam |
8# C steel |
Floor Purlin |
8# C steel |
"A" Shape Beam |
8# C steel |
Pillar |
Double 8# C steel |
Roof Purlin |
L40 angle steel |
Staircase |
Steel |
Aisle Board |
3mm corrugated steel board |
Wall Board |
50mm-200mm EPS (PU, MGO, RW)sandwich panel |
Roof Board |
50mm-200mm EPS (PU, MGO, RW)sandwich panel |
Floor Board |
15mm plywood board |
Window |
PVC sliding window/Aluminum alloy window |
Door |
Sandwich door with aluminum frame/security door/PVC door |
Ceiling |
Gypsum board/Aluminum board |
Water Pipes & upping port Electrics |
Based on standards in local place |
Color |
Sky blue/brick red/greyish white/others colors as per customers' request |
Supporting Facilities |
Toilets, wash basin, air-condition, socket, switch and others as per customers' request |
3. Detailed Parameters
Wind resistance |
Grade11(wind speed≤111.5km/h) |
Earthquake resistance |
Grade 8 |
Live load capacity of roofing |
0.5n/sqm |
External and internal wall heat transmission coefficient |
0.35Kcal/m2hc |
Second floor load capacity |
150Kg/sqm |
Live load of corridor |
2.0Kn/sqm |
4. Product Pictures
normal layout design
5. Component Pictures
