An Ping Wire Mesh Fence ( Wire Mesh Fence Panel + Square/rectangle or round Post + Anti-theft Clips)

Specifications

wire mesh fence
wire:0.5-5.0mm
length:0.5-2.0m,width:0.5-30m
Mesh:1/4",3/8",1/2",5/8",3/4",1"
ISO9001:2008



Wire mesh fence

Wire mesh fencing has a lot of uses from residential to industrial purposes. Over the years, it has slowly taken over chain-link fences because users see it to be more durable. It can be used in Security Fencing, Animal Fencing, Window Screens, Highway and Railway Fencing and so on.

Maretial:

high quality low carbon steel wireQ235, Q195, S235J2, galvanized wire and stainless steel wire.

Process:

Drawing wire--- straightening and cutting---welding--- galvanized--- parkerising--- PVC/powder spraying/dipped coating--- packaging

Colors:

green(RAL6005),blue,white,red,yellow,black RAL9005,gery etc as your request

Property:

Corrosion resistance, aging resistance, sunshine resistance and weather resistance, easy to transport, easy installed.

Application:

Applicable to highway, railway, airport, factory, workshop, residential area, ports, municipal flower garden greenbelt and the decoration protection.

Specification:

Wire dia:

3-5mm for powder spraying; 3-5mm before coating, 4-6mm(after coating) for pvc dipped coated

Peach Post:

50x70mm, 70x100 peach shape post,1.2mm thickness

Finish treatment:

1).electro galvanized+ pvc dipped coated for fence panel
2). PVC spraying coated for peach post



Hole size:  50*200mm 50*100mm 50*150mm 75*150mm



Fence Height:  1.5m 1.6m 1.8m 2.0m 2.2m 2.5m 3.0m etc



Fence width:  1.8m 2.0m 2.5m 3.0m etc



Surface treatment:

1).Hot dip galvanized+PVC coated

2).Electro galvanzied+ PVC coated



Standard specificaiton for peach post fence



Peach Post Fence	Specification Details
Opening (mm)	50x100mm, 50x150mm, 50x200mm, 75x150mm, etc
Wire diameter (galvanized wire)	3-5mm(powder spraying); 3-5mm beofre coating, 4-6mm after coating(pvc coated)
HxW (mm)	height from 0.63-2.40m, width 2m, 2.5, 3.0m
PVC coating thickness (mm)	1.0mm
Peach post (mm)	50x70x1.2mm, 70x100x1.2mm, post height goes with panel height
Surface treatment	wire mesh panel:galvanized+pvc coated, gal.+powder spraying post : galvnaized+powder spraying



Detail picture

Application

Mesh fence post



Packing Detail:

to protect the galvanized wire mesh fences on the trasportation, we pack the panels with steel or wooden pallets, then in plastic film. and special parts will be protected better.



Quotation forwelded wire mesh

If  you want to inquiry, please give us the details below:

1.Wire material

2.Wire diameter

3.Surface treatment  color

4.Length,height,mesh size

5.Order quantity

Payment terms:    30% T/T and after BL 70% T/T or LC at sight

Delivery time: after advance two weeks can be send out for you

If you have any other enquire of the wire mesh fence please contact us in your time as follow, we are glad to give service to you.
