Specifications
1. Wire diameter : 12-31BWG2.Mesh:1"x1/2 " 1"x1" 1/2"x1/2" 1/4"x1/4" 2"x2"
3.width :0.5m-2m
4.Length :10m-30m
1. Welding style:
Hot dipped galvanized after or before weldingElectro galvanized after or before welding
2. Use:
Welded wire mesh is used in industry and agriculture building, transportation and mining for all such purposes as poultry houses, egg baskets, runway enclosures, draining rack, fruit drying screen, fence.
3.Features of welded wire mesh:
1> made of high quality steel wire.
2> various configurations and sizes.
3> used for the loose strata to avoid falling rocks.
4> suitable for shotcrete applications.
5> range of sizes to suit roadway width and bolting patterns.
6> easy installation
7> available in black or hot dip galvanized
8> size of wire aperture: 50x50mm,100x100mm,150x150mm,200x200mm, or 9>ccording to customer request.
10> Max length:6mm
11> width:1200mm,1700mm,2400mm, or according to customer request.
12> diameter of steel wire:3.15mm,4mm,5mm,6mm. or according to customer request
4.pecification as the customer's requirements.
Specification List of Welded Wire Mesh | ||
Opening |
Wire Diameter |
|
In inch |
In metric unit(mm) |
|
1/4" x 1/4" |
6.4mm x 6.4mm |
22,23,24 |
3/8" x 3/8" |
10.6mm x 10.6mm |
19,20,21,22 |
1/2" x 1/2" |
12.7mm x 12.7mm |
16,17,18,19,20,21,22,23 |
5/8" x 5/8" |
16mm x 16mm |
18,19,20,21, |
3/4" x 3/4" |
19.1mm x 19.1mm |
16,17,18,19,20,21 |
1" x 1/2" |
25.4mm x 12.7mm |
16,17,18,19,20,21 |
1-1/2" x 1-1/2" |
38mm x 38mm |
14,15,16,17,18,19 |
1" x 2" |
25.4mm x 50.8mm |
14,15,16 |
2" x 2" |
50.8mm x 50.8mm |
12,13,14,15,16 |
Technical Note:1,Standard roll length: 30m;width: 0.5m to 1.8m2,Special sizes available at request3,Packing: in waterproof paper in rolls. Custom packing available at request. | ||
Galvanized Fencing Mesh | ||
Opening |
Wire Diameter |
|
In inch |
In metric unit(mm) |
|
2" x 3" |
50mm x 75mm |
2.0mm,2.5mm,1.65mm |
3" x 3" |
75mm x 756mm |
2.67mm,2.41mm,2.11mm,1.83mm,1.65mm |
2" x 4" |
50mm x 100mm |
2.11mm,2.5mm |
4" x 4" |
100mm x 100mm |
2.0mm,2.5mm |
Technical Note:1,Standard roll length: 30m;width: 0.5m to 1.8m2,Special sizes available at request3,Packing: in waterproof paper in rolls. Custom packing available at request. | ||
5.packing :in rolls packed with moistureproof paper and plastic film. Custom packing available at request
6.Welcome to send inquiry to me .
