Specifications
Stainless steel wire mesh1.Material : sus 202,302.304 (L) 316 (L) .
2.Mesh :1-650mesh.
3.Wire dia :0.1-3.0mm
stainless steel wire mesh
1. Raw material: 302, 304 304L 316 316L
2. Gauge:
a. Wire diameter: 0.01mm-5mm
b. Mesh: 3-500 mesh
c. Width: 0.5m-5m
d. Length: 30m
3. Weave method:
a. Plain weave
b. twill weave
c. Dutch weave
4. Capability:
a. Acid resistant,
b. alkali resistant
c. high temperature resistant
d. high tensile force
e. wear resistance
5. Uses:
Used for sieving and filtering in acid and alkali conditions. It is also used as slurry mesh in petroleum industry, screen or filter mesh in chemical industry and chemical fibre industry, acid cleaning mesh in electro galvanization industry.
6.stainless steel wire specification :
stainless steel wire mesh | ||||||
mesh/inch |
wire diameter |
aperture |
mesh/inch |
wire diameter |
aperture |
|
2mesh |
1.80 |
10.90 |
60mesh |
0.15 |
0.273 |
|
3mesh |
1.60 |
6.866 |
70mesh |
0.14 |
0.223 |
|
4mesh |
1.20 |
5.15 |
80mesh |
0.12 |
0.198 |
|
5mesh |
0.91 |
4.17 |
90mesh |
0.11 |
0.172 |
|
6mesh |
0.80 |
3.433 |
100mesh |
0.10 |
0.154 |
|
8mesh |
0.60 |
2.575 |
120mesh |
0.08 |
0.132 |
|
10mesh |
0.55 |
1.990 |
140mesh |
0.07 |
0.111 |
|
12mesh |
0.50 |
1.616 |
150mesh |
0.065 |
0.104 |
|
14mesh |
0.45 |
1.362 |
160mesh |
0.065 |
0.094 |
|
16mesh |
0.40 |
1.188 |
180mesh |
0.053 |
0.088 |
|
18mesh |
0.35 |
1.060 |
200mesh |
0.053 |
0.074 |
|
20mesh |
0.30 |
0.970 |
250mesh |
0.04 |
0.061 |
|
26mesh |
0.28 |
0.696 |
300mesh |
0.035 |
0.049 |
|
30mesh |
0.25 |
0.596 |
325mesh |
0.03 |
0.048 |
|
40mesh |
0.21 |
0.425 |
350mesh |
0.03 |
0.042 |
|
50mesh |
0.19 |
0.318 |
400mesh |
0.025 |
0.0385 |
|
Width of Stainless Steel Wire Mesh: 0.6m-1.5m | ||||||
6.The production process :
7. Payment terms: 30%TT in advance; 70% against B/L copy.
8.Packing :
Wrapped with moister-barrier paper, then in wooden cases.
9.The stock :
10.Application :
Welcome to send inquiry to me :
