Window Screen/window Screening/stainless Steel Security Window Screen Mesh

Window Screen/window Screening/stainless Steel Security Window Screen Mesh photo-1
US$ 10 - 20 MOQ: 500 Rolls
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
tianrui
Model Number:
304 316
Payment & Shipping
Payment Methods:
Port of Shipment:
xingang
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Hebei, China
Brand Name tianrui
Model Number 304 316
Screen Netting Material Stainless Steel

Specifications

Specification :
1.Material : SS 304/316/304L/316L
2.Wire dia:0.2-2.0mm
3.Mesh: 20*20,18*18,16*16,18*16,18*14
4.ISO 9001

 Stainless steel window screen



Wire diameter: 0.2mm-2.0mm

Mesh: 20*20,18*18,16*16,18*16,18*14

Material: SS304,304L,316,316L

Width :0.8-1.5m

Weave: plain weave and twill weave

We offer stainless steel window screen in different materials,widely used in hotels and buildings to prevent insects and bugs from entering.

Features: acid resistant, alkali resistant, high temperature resistant, high tensile force and wear resistance.

Property:keep out flies, wasps, bees, mosquitoes and other insects but not midges, provides excellent light transmission and allows good air-flow. Have Good stability and resistance to rust, heat, acid, alkaline and corrosion.

window screen/window screening/stainless steel security window screen mesh



window screen/window screening/stainless steel security window screen mesh



Advantages:
1. Allows superior airflow
2. Improved visibility and good stability
3. Anti-corrosion and rust resistance
4. Lighter weight
5. Nice appearance
6. Much stronger than standard insect screen
7.Heat and acid resistance, therefore it could be applied under high temperature workshops and civil construction .



Specification :



Specification List of Stainless Steel Wire Mesh
Mesh/InchWire Gauge(SWG)Aperture in mm
3mesh x 3mesh146.27
4mesh x 4mesh164.27
5mesh x 5mesh183.86
6mesh x 6mesh183.04
8mesh x 8mesh202.26
10mesh x 10mesh201.63
20mesh x 20mesh300.95
30mesh x 30mesh340.61
40mesh x 40mesh360.44
50mesh x 50mesh380.36
60mesh x 60mesh400.30
80mesh x 80mesh420.21
100mesh x 100mesh440.172
120mesh x 120mesh440.13
150mesh x 150mesh460.108
160mesh x 160mesh460.097
180mesh x 180mesh470.09
200mesh x 200mesh470.077
250mesh x 250mesh480.061
280mesh x 280mesh490.060
300mesh x 300mesh490.054
350mesh x 350mesh490.042
400mesh x 400mesh500.0385
Roll width: 2'-8'



 window screen/window screening/stainless steel security window screen mesh



window screen/window screening/stainless steel security window screen mesh



window screen/window screening/stainless steel security window screen mesh



window screen/window screening/stainless steel security window screen mesh



window screen/window screening/stainless steel security window screen mesh



window screen/window screening/stainless steel security window screen mesh



window screen/window screening/stainless steel security window screen mesh



Application: Widely used for windows and corridors to prevent insects from interrupting widely used in architectures, husbandry, gardens, hotels and other sites that preventing mosquito







window screen/window screening/stainless steel security window screen mesh



window screen/window screening/stainless steel security window screen mesh



window screen/window screening/stainless steel security window screen mesh





Packing :



window screen/window screening/stainless steel security window screen mesh



window screen/window screening/stainless steel security window screen mesh
