Hexagonal Wire Netting Machine
1.They are classified five types according to the different opening:1,1 1/4,11/2, 2, 3.
The machine can continuously work.
2.Characteristics: Smooth running, low noise, automatically stop and given an alarm when theres something wrong
3.Scope of wraving: 1.22m double width or 2.44m single width
4.Used clutch arrester, neatly handle concentrate lubricating system, simply operate
5.The motors power: 2.2KW. Three-phase current
Type | Width | Distance of mesh hole | Wire diametr | Twist times | Weight | Power | ||
mm | in | mm | SWG | |||||
LJW20-12 | 1200-2000 | 12 | 3/8 | 0.40 | 27 | 3 | 2500 | 3 |
LJW20-15 | 1200-2000 | 15 | 1/2 | 0.50 | 25 | 3 | 2500 | 3 |
LJW20-18 | 1200-2000 | 18 | 5/8 | 0.55-0.70 | 24-22 | 3 | 2500 | 3 |
LJW20-22 | 1200-2000 | 22 | 3/4 | 0.70-0.90 | 22-20 | 3-5 | 2500 | 3 |
LJW20-27 | 1200-2000 | 27 | 1 | 0.70-0.90 | 22-20 | 3-5 | 2500 | 3 |
LJW20-32 | 1200-2000 | 32 | 1-1/4 | 0.70-0.90 | 22-20 | 3-5 | 2500 | 3 |
LJW20-44 | 1200-2000 | 44 | 1-1/2 | 0.90-1.2 | 20-18 | 3-5 | 2500 | 3 |
LJW20-54 | 1200-2000 | 54 | 2 | 0.90-1.2 | 20-18 | 3-5 | 2500 | 3 |
LJW20-76 | 1200-2000 | 76 | 3 | 1.2-1.6 | 18-16 | 3-5 | 4000 | 5.5 |
LJW20-94 | 1200-2000 | 94 | 3-1/2 | 1.6-2.0 | 16-14 | 3-5 | 6000 | 7.5 |
LJW20-94A | 1200-2000 | / | 3-1/2 | 2.0-3.5 | 14-10 | 3-5 | 12000 | 15 |
LJW20-110A | 1200-2000 | / | 4 | 2.0-3.50 | 14-10 | 3-5 | 12000 | 15 |
