CE approved good price pine sawdust dryer machine
Wood chips sawdust dryer is mainly consist of rotary body, raw material feeding plate, driving and supporting device, etc. Its principle of operation: the raw material plate which is arranged reasonably with changeable angles in order, throws moisture materials into the rotary cylinder. Then water will be separated from the materials by hot air-flow and changed into vapour to be discharged into the atmosphere. Then the materials would be dryed.
1. Sawdust drying equipments include heating furnace, feed port, rotating cylinder, delivery pipe, dirt catcher and discharge port.
2. Wet sawdust is continuously sent to the drying cylinder by a conveyor.
3. The material boils and fluidifies in the cylinder. Heat air makes full contact with the material.
4. Being delivered and scattered by the high-speed hot air, water in the wet material is evaporated.
5.The sawdust gets fully dried in the rotating cylinder, thus the quality is ensured.
1. BSM Sawdust rotary dryer is mainly composed of cylinder, under frame, feeding and discharging devices, transmission device, gear cover, etc.
2. Optional auxiliary equipment includes combustion chamber, feeder and discharging device, and dust collection equipment).
3. BSM sawdust dryer is manufactured by adopts new lifting plate, which is of functions like guiding, current-sharing, and material rising. The materials are raised and evenly drop so that they are in full contact with heat for better drying efficiency.
1. Dry strongly and shortly. The moisture in the after-drying sawdust is even and steady.
2. Big and small transmission gears adopt pin column replaceable gear, instead of traditional steel casting gear, saving investment cost, and greatly reduce the repair cost and time.
3. Large handling capacity and high heat efficiency. When drying unbound water, its heat efficiency can reach 60%.
| Model | Diameter (mm) | Length (mm) | Slope (°) | Rotary Speed (r/min) | Weight (t) | Power (KW) | Volume (m³) |
| 0.6x8 | 600 | 8000 | 3-5 | 8 | 5.1 | 6-4 | 2.26 |
| 0.8x10 | 800 | 10000 | 3-5 | 7.2 | 6.9 | 6-4 | 5.02 |
| 1.0x10 | 1000 | 10000 | 3-5 | 6.73 | 7.5 | 6-5.5 | 7.85 |
| 1.2x12 | 1200 | 12000 | 3-5 | 5.8 | 13.1 | 6-11 | 13.31 |
| 1.5x12 | 1500 | 12000 | 3-5 | 4.8 | 22.3 | 6-15 | 21.2 |
| 2.2x14 | 2200 | 14000 | 3-5 | 3.2 | 52.8 | 30 | 53.22 |
| 2.4x18 | 2400 | 18000 | 3-5 | 3 | 73.3 | 37 | 81.43 |
| 2.8x24 | 2800 | 24000 | 3-5 | 2.59 | 97 | 75 | 147.8 |
1>Pre-sale services: Enthusiasm
We provide you with the prophase plan, process flow design and manufacturer equipment according to your special demand.
2>Sale services: Servant
Send technicians to the jobsite for guiding the installation and adjustment, training operators and finishing the check and accept together with you.
3>After-sale services: Faithfulness
To establish long term friendship, we will regularly pay return visit to customers. Supplying technique, building design, instruction, installation and debugging for free.
4>Warranty
We provide two-years warranty to make sure your machine runs consistently. We always offering life long services and provide spare parts for a long term,and repair main parts under right using for free in two years.
5>What if we are new in this business?
Many thanks for your trust.
WE can help you provide deisign scheme for complete production lines, spot inspection and operator training based on your demand. According to your workshop condition, we can help you choose the right equipments. So don't worry.
1>How is the quality of your products?
Our products are manufactured strictly according to national and international standard, and we take a test on every machine before delivery.
2>What guarantee do you provide?
If products’ quality is not consistent with the description as we described or the promise before you place order, we promise 100% refund.
3>How about price?
Yes, we are factory and be able to give you the lowest price than market one, and we have a policy that “ for saving time and absolutely honest business attitude,we quote as low as possible for any customer, and discount can be given according to quantity”.
