FRP Grating/Various Specification Glass Fiber Reinforced Plastic Grating
FRP grating is a kind of glass fiber reinforced material, unsaturated polyester resin as matrix, through special processing of fusion with the blank space of plank, it can do structure materials, used in corrosive environment, trench cover, platform, car wash plate, stair, tree perforated strainer, drain cover plate, etc.
Features:
1) Strong corrosion resistance
Glass fiber reinforced plastic grating has a strong acid and alkali resistance, resistance to organic solvents and other performance of gas, liquid medium, has incomparable superiority in the field of anti-corrosion.
2) Light quality, high strength
Glass fiber reinforced plastic grating is resin and composite yarn, density is less than 2 kg each CDM, weight much less than the weight of the steel and aluminum.But when the strength of plastic more than 10 times, than the strength of the ordinary steel and aluminium.
3) Convenience of cutting and installation
Glass fiber reinforced plastic grating is made of resin and yarn fusion, with normal power saws and hacksaw can be easily cut.Because of light weight, high strength, so don't need large hoisting equipment at the same time also do not need strong support.
4) Ageing resistance
The service life of FRP gratings in more than 20 years, car wash with grating plate in commonly 7 to 8 years.
5) High security
Glass fiber reinforced plastic grating has good electrical insulation, 10 kv voltage without breakdown;Without electricity, magnetic available in sensitive to magnetic devices;It also has a special structure to prevent slip, fatigue resistance and so on characteristics.
Glass fiber reinforced plastic grille type:
38 mm model, mainly used in car washing industry.
25 mm model, mainly used in the gutter cover, tree perforated strainer, etc.
30 mm model, application platform in the factory or pedal, etc.
Specification:
Item No. |
Height(mm) |
Mesh Size(mm) |
Standard Panel Size (mm) |
Open Area |
Weight(kg/m2)
|
| 1 | 15 |
38 × 38 |
1220 × 3660 |
72% |
6.00 |
| 2 | 15 | 20 × 20 40 × 40 |
1247×4047,1007×4047 | 42% | 9.00 |
3 |
25 |
38 ×38 |
997 × 3050 , 1220 × 3660 |
69% |
12.32 |
4 |
25 |
40 × 40 |
1007 × 3007 , 1007 × 4007, 1007 × 4047 , |
67% |
12.20 |
5 |
25 |
25 × 100 |
1009 × 3007 ,1209 ×3657 |
67% |
13.87 |
| 6 | 30 | 38 × 38 | 1220 × 3660 , 997 × 3050 | 69% | 14.60 |
7 |
30 |
40 × 40 |
1007 × 3007 , 1007 × 4007 |
67% |
14.28 |
8 |
30 |
20 × 20 40 × 40 |
1000 × 4000,1247×4047 |
42% |
18.10 |
| 9 | 38 | 38 × 38 |
997 × 3050 , 1220 × 3660 |
68% |
19.71 |
10 |
38 |
25 × 152 |
1226 × 3665 (Bearing bars to run length direction) |
56% |
22.40 |
| 11 | 38 |
20 × 20 40 × 40 |
1007 × 4007,1247×4047 |
42% |
22.50 |
12 |
40 |
40 × 40 |
1007 × 3007 , 1007 × 4007 |
67% |
19.87 |
13 |
40 |
20 × 20 40 × 40 |
1247 × 4047 |
42% |
23.70 |
14 |
50 |
50.7 × 50.7 |
1225× 3660 |
69% |
22.17 |
| 15 | 60 | 38 × 38 | 1220 × 3660 | 47% | 50.43 |
