200mA 20kw for whole body radiology photography x ray equipment
Model:YSX200G
Good market 20kw high frequency medical x ray machine for sale
Features of 20kw high frequency x-ray equipment:
1.High precision control mode through analog & digital double-loop control: Adopting HF (≥30kHz)inverter circuit combined with analog & digital double-loop control mode (composed of microprocessor and PWM dedicated chip), in order to achieve high-precision high voltage output. Though power supply fluctuation may appear, steady x-rays can still be output.
2.High precision control in radiography time: Minimum exposure time is 0.0025 second, and quick radiography is accessible at any time without the influence of power phase, thus high-quality x-ray films are easily achieved and x-ray radiation to patients is reduced.
3.High-precision tube current control: X-ray tube current using two high-frequency converter heating which is controlled by the microprocessor high-speed A / D converter sampling tube current calculate in real-time. The microprocessor control the allow load of the X-ray tube. It can be set out photographic conditions of expressing an effective X-ray tube capacity.
Technical index of main component for 20kw high frequency x-ray equipment :
CONTENTS |
YSX200G |
|
Intermittent mode |
100kV ,200mA,20kW |
|
Power Voltage |
380V±10% 50Hz±10% |
|
Tube current |
Radiography 16mA~200mA |
|
Output Voltage |
Radiography 40-125KV step 1kV; |
|
Resistance power |
less than 0.5Ω |
|
Output power |
20kW |
|
Exposure Time |
Radiography 0.0025s~6.4s adjustable |
|
Nominal Frequency |
30kHz |
|
Speed of anode rotating |
2800r/min |
|
Anode heat capacity |
140KHU |
|
Focus |
Small focus:1.0mm Big focus:2.0mm |
|
Length*width*height of bed surface |
2000mm×750mm×690mmDeviation:±10mm |
|
Horizontal movement distance of table |
≥200mm |
|
Vertical movement distance of table |
≥900mm |
|
Distance from table surface to film |
50mm±2mm |
|
Distance of vertical movement |
770mm±10mm; |
|
Moving crosswise (left & right) |
+180°~-180°deviation<±2° |
|
Moving lengthways (along ground railway) |
≥1300mm |
|
Fixed beam filtration grid density |
≥40 lines/cm |
|
grid ratio |
10:01 |
|
Focus Distance |
100cm |
|
Cassette size |
5″×7″ 8″×10″ 10″×12″ 11″×14″ 14″×17 ″ |
|
Configuration:
No |
Part Name |
Qty |
1 |
X-ray tube |
1 |
2 |
Radiographic Table |
1 |
3 |
Collimator |
1 |
4 |
Microcomputer console |
1 |
5 |
High-voltage generator, |
1 |
6 |
High voltage cable |
2 |
7 |
Vertical bucky stand |
1 |
High performance good price 20kw high frequency x-ray equipment
cheapest 20kw high frequency x-ray equipment prices
medical radiography 20kw high frequency x-ray equipment
20kw high frequency x-ray equipment
20kw high frequency x-ray equipment for sale
