AS4060/AXK4060 High Quality Thrust Needle Roller Bearing
US$ 0.34 - 2.56
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
TBB/OEM
Bore Size:
25, 65
Outside Diameter:
42, 90
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hot Sale Thrust Needle Roller Bearing Washer AS4565 AXK4565US$ 0.34 - 2.56MOQ: 1 Piece -
Heavy-duty Needle Roller Bearing With Inner Ring NA4901US$ 0.55 - 9.99MOQ: 100 Pieces
-
TBB STANDARD SERIES NEEDLE ROLLER BEARING WITH INNER RING NA4905US$ 1.13 - 9.99MOQ: 100 Pieces
-
HEAVY-DUTY NEEDLE ROLLER BEARING WITH INNER RING NA4906US$ 1.25 - 9.99MOQ: 100 Pieces
-
TBB STANDARD INNER RING NEEDLE ROLLER BEARING NA4907US$ 1.48 - 9.99MOQ: 100 Pieces
Brand Name
TBB/OEM
Bore Size
25, 65
Outside Diameter
42, 90
Model Number
AS4060/AXK4060
Precision Rating
P0 P6 P5 P4 P2
Number of Row
Single Row
Place of Origin
Shanghai, China
Product Display
Product Display / Details
Product Parameters
Product Parameters
China-made axial bearing washer AS4060 AXK4060
Thrust Washer & Thrust Needle Roller Bearing details:
Thrust Washers
Use as fatigue liners for soft housing faces. Combine with needle roller and cage assembly to form a complete needle roller thrust bearing.
Use as fatigue liners for soft housing faces. Combine with needle roller and cage assembly to form a complete needle roller thrust bearing.
Product content provided by supplier
Specifications:
1) Standard material according to technical drawing
2) OEM quality standard guaranteed
3) Long lasting working life time
4) Positive customer feedback from abroad and domestic market
5) Long exporting history;
6) Competitive price level
7) Able to produce according to specification with technical drawing
8) Sample purpose order accepted
9) Packing according to specification required
10) Flexile and convenient logistic service
1) Standard material according to technical drawing
2) OEM quality standard guaranteed
3) Long lasting working life time
4) Positive customer feedback from abroad and domestic market
5) Long exporting history;
6) Competitive price level
7) Able to produce according to specification with technical drawing
8) Sample purpose order accepted
9) Packing according to specification required
10) Flexile and convenient logistic service
Part of the bearing specification :
| Thrust | Shaft Dia | Bearing | Mass | Housing | Mass | Dimension(mm) | ||
| needle roller bearing | (mm) | Washer | Approx (g) | Locating Washer | Approx (g) | d | D | B1 |
| AXK0414TN | 4 | AS0414 | 1 | 4 | 14 | 2 | ||
| AXK0515TN | 5 | AS0515 | 1 | 5 | 15 | 2 | ||
| AXK0614TN | 6 | AS0614 | 1 | 6 | 14 | 2 | ||
| AXK0619TN | 6 | AS0619 | 2 | 6 | 19 | 2 | ||
| AXK0821TN | 8 | AS0821 | 2 | 8 | 21 | 2 | ||
| AXK1024 | 10 | AS1024 | 3 | 10 | 24 | 2 | ||
| AXK1226 | 12 | AS1226 | 3 | 12 | 26 | 2 | ||
| AXK1528 | 15 | AS1528 | 3 | GS81102 | 8 | 15 | 28 | 2 |
| AXK1722 | 17 | AS1722 | 3 | 17 | 22 | 2 | ||
| AXK1730 | 17 | AS1730 | 4 | GS81103 | 9 | 17 | 30 | 2 |
| AXK2035 | 20 | AS2035 | 5 | GS81104 | 12 | 20 | 35 | 2 |
| AXK2542 | 25 | AS2542 | 7 | GS81105 | 19 | 25 | 42 | 2 |
| AXK3047 | 30 | AS3047 | 8 | GS81106 | 20 | 30 | 47 | 2 |
| AXK3552 | 35 | AS3552 | 9 | GS81107 | 27 | 35 | 52 | 2 |
| AXK4060 | 40 | AS4060 | 12 | GS81108 | 37 | 40 | 60 | 3 |
| AXK4565 | 45 | AS4565 | 13 | GS81109 | 47 | 45 | 65 | 3 |
| AXK5070 | 50 | AS5070 | 14 | GS81110 | 51 | 50 | 70 | 3 |
| AXK5578 | 55 | AS5578 | 18 | GS81111 | 82 | 55 | 78 | 3 |
| AXK6085 | 60 | AS6085 | 22 | GS81112 | 92 | 60 | 85 | 3 |
| AXK6590 | 65 | AS6590 | 24 | GS81113 | 110 | 65 | 90 | 3 |
| AXK7095 | 70 | AS7095 | 25 | GS81114 | 120 | 70 | 95 | 4 |
| AXK75100 | 75 | AS75100 | 27 | GS81115 | 136 | 75 | 100 | 4 |
| AXK80105 | 80 | AS80105 | 28 | GS81116 | 144 | 80 | 105 | 4 |
| AXK85110 | 85 | AS85110 | 29 | GS81117 | 151 | 85 | 110 | 4 |
| AXK90120 | 90 | AS90120 | 39 | GS81118 | 225 | 90 | 120 | 4 |
| AXK100135 | 100 | AS100135 | 50 | GS81120 | 350 | 100 | 135 | 4 |
| AXK110145 | 110 | AS110145 | 55 | GS81122 | 385 | 110 | 145 | 4 |
| AXK120155 | 120 | AS120155 | 59 | GS81124 | 415 | 120 | 155 | 4 |
| AXK130170 | 130 | AS130170 | 65 | GS81126 | 643 | 130 | 170 | 5 |
| AXK140180 | 140 | AS140180 | 79 | GS81128 | 749 | 140 | 180 | 5 |
| AXK150190 | 150 | AS150190 | 84 | GS81130 | 796 | 150 | 190 | 5 |
| AXK160200 | 160 | As160200 | 89 | Gs81132 | 842 | 160 | 200 | 5 |
