CL Type Gear Couplings
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Structure:
Gear
Flexible or Rigid:
Rigid
Standard or Nonstandard:
Standard
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Structure
Gear
Flexible or Rigid
Rigid
Standard or Nonstandard
Standard
Material
Steel
Model Number
CL type
Specifications
CL type gear couplingsCL type gear couplings
| Parameters and main dimensions:(JB/ZQ 4218-86) mm | ||||||||
| Type | D | D1 | B | C | ||||
| Tn | Y,J1,Z1 | kg | ||||||
| N.m | d1,d2,d3 | L | ||||||
| CL1 | 710 | 18,19 | 30,42 | 170 | 110 | 106 | 16 | 7.8 |
| 20,22,24 | 38,52 | 6 | ||||||
| 25,28 | 44,62 | 2.5 | ||||||
| 30-40 | 60-112 | |||||||
| CL2 | 1400 | 30,32,35,38 | 82,60 | 185 | 125 | 134 | 2.5 | 12.5 |
| 40-50 | 84-112 | |||||||
| CL3 | 3150 | 40-56 | 112,84 | 220 | 150 | 170 | 2.5 | 26.9 |
| 60 | 142,107 | |||||||
| CL4 | 5600 | 45-56 | 112,84 | 250 | 175 | 200 | 2.5 | 34.9 |
| 60-75 | 142,107 | |||||||
| CL5 | 8000 | 50-90 | 84-172 | 290 | 200 | 220 | 5.0 | 55.8 |
| CL6 | 11200 | 60-110 | 107-212 | 320 | 230 | 246 | 5.0 | 79.9 |
| CL7 | 18000 | 65-75 | 142,107 | 350 | 260 | 286 | 5.0 | 109.5 |
| 80-120 | 132-172 | |||||||
| CL8 | 22400 | 80-95 | 172,132 | 380 | 315 | 325 | 5.0 | 133.8 |
| 100-140 | 167-252 | |||||||
| CL9 | 28000 | 90,95 | 172,132 | 430 | 365 | 335 | 5.0 | 171.0 |
| 100-160 | 167-302 | |||||||
| CL10 | 50000 | 110-180 | 167-302 | 490 | 420 | 365 | 5.0 | 275.8 |
| CL11 | 71000 | 120,125 | 212,167 | 545 | 470 | 405 | 5.0 | 385.0 |
| 130-220 | 202-352 | |||||||
| CL12 | 100000 | 140,150 | 252,202 | 590 | 520 | 485 | 5.0 | 540.0 |
| 160-250 | 242-410 | |||||||
| CL13 | 140000 | 160-280 | 242-470 | 680 | 590 | 524 | 7.5 | 798.3 |
| CL14 | 200000 | 180-320 | 242-470 | 730 | 650 | 565 | 7.5 | 976.6 |
| CL15 | 250000 | 220-360 | 282-550 | 780 | 700 | 644 | 7.5 | 1182.5 |
| CL16 | 335000 | 240-400 | 330-650 | 900 | 785 | 720 | 10.0 | 1936.0 |
| CL17 | 560000 | 260-450 | 330-650 | 1000 | 885 | 800 | 10.0 | 2700.0 |
| CL18 | 710000 | 300-500 | 380-650 | 1100 | 990 | 900 | 10.0 | 3669.0 |
| CL19 | 1000000 | 360-560 | 450-800 | 1250 | 1090 | 910 | 15.0 | 5138.0 |
