Place of Origin Jiangsu, China
Brand Name NANTONG JAKARTA
Model Number CXH-11P
Part Other, fixture

China suppliers 2015 Marine Single-deck navigation singal light CXH-11P

Specifications

Marine Navigation Signal light IP56
Applied to ships with length 50M or above 50M
Type:CXH-11P
Lampholder:P28S

 China suppliers 2015 Marine Single-deck navigation singal light CXH-11PChina suppliers 2015 Marine Single-deck navigation singal light CXH-11P



The scope of application:



Applied to the ships with the length 50m or above 50m as lamp signal liaision when night navigation.



Characteristics:



1.The shell is made of high intensity engineering plastics PA+GF, the lampshade adopts injuection  of PC, lens hood adopts good quality stainless steel.



2.The signal lights have the whole seal structure, it is waterproof under the bad environment.



3. The signal light choose the special signal bulb which conform to the ship crterion, it can replace  the up and down bulb as open cover.



4.The signal lights adopt the signal light's bulb which conform to the ship norm, and the average life  is not lower than 700h.



5. The signal lights can work normally under the temperature of -30 to +50°C



Production authentication:



1.Approved by CCS (China Classification Society), and ZY of China Fishery Inspection.



2.Passed the authentication of CE



3.Approved by Germanischer Lloyd “GL”



4.Approved by MED/EC



Adopt standard:


1. Conform to THE INTERNATIONAL REGULATIONS FOR PREVENTINGS COLLISION AT SEA,  1972 and GRADE ENTRY NORMS FOR STEEL SHIPS.


2. Conform to the international standard IEC60598-1-2008


3. Conform to the standard of marine electric signal light’s technical condition GB/T 3028-12012.



Voltage

24V

110V

220V

Power

60W

60W

65W

Luminous intensity



Lamp holder

B22d

Protection class

IP56

Cable outside Diameter

Ø9



Name

Model

Visible

Level arc

Color

Weight

Starboard light

CXH1-11P

3n.m

112.5°

Green

3.2kg

Port light

CXH2-11P

3n.m

112.5°

Red

3.2kg

Masthead light

CXH3-11P

6n.m

225°

white

3.2kg

Stern light

CXH4-11P

3n.m

135°

White/Yellow

3.2kg

All-round  light

CXH6-11P

3n.m

360°

Red/Green/white

3.2kg



 Packaging:

China suppliers 2015 Marine Single-deck navigation singal light CXH-11P

Shipping:
1. FedEx/DHL/UPS/TNT for samples, Door-to-Door;

2. By Air or by Sea for batch goods, for FCL; Airport/ Port receiving;

3. Customers specifying freight forwarders or negotiable shipping methods!

4. Delivery Time: 1-3 days for samples; 10-15 days for batch goods.

Payment Terms:
1. Payment: T/T, L/C; 30% deposits; 70% balance before delivery.

2. MOQ: 100pcs

3. Warranty :  18 month

4. Package Informations: Depends on the volume of goods.
