Hots Sale Semi Trailer Truck Trailer From JYD

Nantong Jakarta Trade Co., Ltd.

US$ 1 - 999,999 MOQ: 1 Set

Key Specifications

OEM No.:

CIMT

Max Payload:

40T-50T

Size:

12.5*2.5*1.57M

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI QINGDAO

Delivery Detail:

Delivery time depends on order quantity.

OEM No. CIMT

Max Payload 40T-50T

Size 12.5*2.5*1.57M

Place of Origin Jiangsu, China

Brand Name JKD

Model Number Semi-Trailer, container semi trailer

TECHNICAL PARAMETER

Chassis and main parts
DIMENSION	12450mm2490mm1557mm,Size can be design depends on customers’ request
AXLES	13 T/PER axle, FUWA /BPW/HJ brands for choose
RIM	9.00-22.5 13PCS or other sizes
TIRE	12R22.5-22.5 13 PCS or other sizes , Triangle/Double Coin/Linglong
SUSPENSION	Mechanical suspension or Airbag suspension
LEAF SPRING	90(W)mm13(Thickness)mm10 Layer or 100mm12mm12 Layer
KINGPIN	JOST brand 2.0 or 3.5inch bolts type
LANDING LEG	JOST brand C200T or China brand 28Tons (Double speed)
MAIN BEAM	Height: 450mm-520mm, upper plate is 14mm-16mm, middle plate is 8mm-12mm,
MAIN BEAM	down plate is 16mm-20mm ; Material is Q345B standard steel .
SIDE BEAM	16mm -25mm channel steel (Material is Q235B standard steel ).
PLATFORM	Standard 3 mm thickness checkered plate
BRAKING SYSTEM	WABCO brand emergency valve, T30/30+T30 Spring brake chamber, one piece of 45L air tank , ABS is optional
TWIST LOCKS	4 or 8 or 12PCS (lift and screw type for choose)
ELECTRIC SYSTEM	Voltage is 24V / 7 ways (7 wire harness) / LED light
TOOL BOX	One piece ,equipped with 1 unit Tire spanner, 1 piece sleeve and 1 piece cranking bar)
PAINTING	Complete Chassis sand blasting to clean rust, 1 coat of anti corrosive prime, 2 coats of final paint
OTHERS	Design and make the right trailer depends on customers’ request
