Top Manufacturer Supply 30kw Three Phase Smart Mppt pv Water Pump Inverter for Irrigation

Top Manufacturer Supply 30kw Three Phase Smart Mppt pv Water Pump Inverter for Irrigation thumbnail-1
Top Manufacturer Supply 30kw Three Phase Smart Mppt pv Water Pump Inverter for Irrigation thumbnail-2
Top Manufacturer Supply 30kw Three Phase Smart Mppt pv Water Pump Inverter for Irrigation thumbnail-3
Top Manufacturer Supply 30kw Three Phase Smart Mppt pv Water Pump Inverter for Irrigation thumbnail-4
Top Manufacturer Supply 30kw Three Phase Smart Mppt pv Water Pump Inverter for Irrigation thumbnail-5
Top Manufacturer Supply 30kw Three Phase Smart Mppt pv Water Pump Inverter for Irrigation thumbnail-6
Top Manufacturer Supply 30kw Three Phase Smart Mppt pv Water Pump Inverter for Irrigation photo-1
Top Manufacturer Supply 30kw Three Phase Smart Mppt pv Water Pump Inverter for Irrigation photo-2
Top Manufacturer Supply 30kw Three Phase Smart Mppt pv Water Pump Inverter for Irrigation photo-3
Top Manufacturer Supply 30kw Three Phase Smart Mppt pv Water Pump Inverter for Irrigation photo-4
Top Manufacturer Supply 30kw Three Phase Smart Mppt pv Water Pump Inverter for Irrigation photo-5
Top Manufacturer Supply 30kw Three Phase Smart Mppt pv Water Pump Inverter for Irrigation photo-6
US$ 2,200 - 2,800 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Anhui, China
Brand Name:
Jntech,OEM
Model Number:
JNP30KH
Contact Supplier Request Quote Chat Now
Hefei Jntech New Energy Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Anhui, China
Brand Name Jntech,OEM
Model Number JNP30KH
Output Power 1 - 200KW
Output Type Triple
Size 46*58*25cm
Weight 32kg
Input Voltage 880Vdc
Output Voltage 380-460Vac
Type DC/AC Inverters
Output Frequency 0~50/60 Hz
Output Current 57A

top manufacturer supply 30kw three phase smart mppt pv water pump inverter for irrigation

Product Description
Features:
1. Drive power-matched three-phase AC pump
2. Adopt advanced IGBT power module
3. High conversion efficiency,low temperature rise,low noise,long lifespan
4. Advanced MPPT technology,efficiency>99%
5. Fully automatic operation,it can store operation data for 10 years
6. Perfect system protection,high reliability
7. New design of anodized alumium case
8. LCD display
9. Interface:RS485/GPRS
10.Modular design,easy to install,operate,maintain
 top manufacturer supply 30kw three phase smart mppt pv water pump inverter for irrigation
Technical Parameters
Model JNP11KH JNP15KH JNP18K5H JNP22KH JNP30KH JNP37KH JNP45KH JNP55KH
d.c. Input
d.c. Max .Input Voltage 880Vdc
Recommended MPPT Voltage 460~850Vdc
d.c. Max. Input Current 24.4A 33.3A 41.1A 49A 67A 82A 100A 122A
Max. MPPT Efficiency 99%
Number of  String 3 1
a.c. Output
Max. Motor Output Power 11kW 15kW 18.5kW 22kW 30kW 37kW 45kW 55kW
Rated Output Voltage 380~460Vac, 3-phase
Output Frequency Range 0~50/60Hz
Rated Output Current 21A 29A 36A 42A 57A 71A 86A 104A
Mechanical Data
Dimensions(W/H/D) 305*430*190mm
Weight 15.1kg 15.1kg  15.1kg
Max. Efficiency 98%
Protection Class I
Protection Level IP65
Operating Temperature Range      -25℃ to +60℃,above 60℃ need derate operating
Cooling Method Force cooling
Display  LCD
Communication Interface RS485/GPRS
Altitude 3000m; above 3000m need derate operating
Noise Emission <50dB
Compliance    EN 50178; IEC/EN 62109-1; IEC 61800



Packaging & Shipping

top manufacturer supply 30kw three phase smart mppt pv water pump inverter for irrigation



Certifications

top manufacturer supply 30kw three phase smart mppt pv water pump inverter for irrigation



On-Site Project Reference:

top manufacturer supply 30kw three phase smart mppt pv water pump inverter for irrigationtop manufacturer supply 30kw three phase smart mppt pv water pump inverter for irrigation

Extra service

Design software to make the system configuration automatically.

top manufacturer supply 30kw three phase smart mppt pv water pump inverter for irrigationtop manufacturer supply 30kw three phase smart mppt pv water pump inverter for irrigationtop manufacturer supply 30kw three phase smart mppt pv water pump inverter for irrigation



Monitoring System:

Features:

1).Control the solar pumping inverter remotely;

2).Manage all solar pumping inverters and systems;

3).Check system operating status at any time;

4).Read all system information on PC,Iphone,Ipad and any other electronic device;

5).Get alarm record and error code once the system failed to operate;

6).Analyse the data to check if the system is in good working condition.

top manufacturer supply 30kw three phase smart mppt pv water pump inverter for irrigation



Company Information

Jntech New Energy technology Co., Ltd was established in 2006. which is an engineer oriented high-tech company with a portfolio of diversified products and services.

Jntech is marketing High Technology Equipment and Solutions in different solar areas. From EPC or BOT(BT) of solar power plant to R & D, manufacturing of key equipment and stand alone system solution provider,

Jntech has come a long way in the past 10years.

Numbers of Jntech:

Registered capital: 100 million RMB

Employee: over 200(50% of  R&D and technical engineers)

Total EPC projects: 1000MW(grounded/ rooftop)

Residential off-grid system: 40,000 units(over 20MW)

Solar pumping system: over 2200 projects in 30 countries

top manufacturer supply 30kw three phase smart mppt pv water pump inverter for irrigation

Welcome to visit our company!
