Solar Off Grid Controller Inverter 3kW

Specifications

Solar Off Grid Controller Inverter 3kW
PWM control Technology
High conversion efficiency
Bypass Grid power as option

Solar Off Grid Controller Inverter 3kW

Technical Characters:

High-frequency conversion and Tandem PWM control Technology, High conversion efficiency

A "point-type" control and current and voltage pairs of closed-loop control, maximizing charging capacity from PV module to battery, improving charging efficiency

Part of unit has LED, LCD display, timely monitoring and displaying battery voltage, load & charging current, daily power generated and discharged amount, total power generated and discharged amount, load shortage times, environment temperature, AC output voltage & current and so on.

System is programmable for parameters of battery, PV module, system and time.

Part of units has RS232/RS485 connect interface

System has RTC function, would be able to check current time and manage to change the time parameters

Man-machine interface LCD could display working parameters and faults for some units

Setting to open/off machine function

Controller and inverter in one body, with bypass Grid power connection as option

Charge and power use in the same while when day time, reliable output voltage and frequency

Multi protection functions, over charge & discharge, over load, shortage, Reverse polarity, over voltage, over heat protections or warning buzzer. And all protection would be auto recover itself. Safety meet: IEC61173, IEC 60529, IEC 62109 and so on

Economy:

The new energy powers are generally high costs, solar PV panel is expensive, to improve efficiency of power machine would properly save solar panels and reduce investment

Easy design:

The power machine integrates controller, inverter and necessary electric parts together in one body, easy diagram, save cost but multi functions



Type			Unit	JNOG1103K
Rated Output Capacity			kVA	3
DC input	Rated Input Power		Vdc	110V
	Under voltage		Vdc	72
	Under voltage Recover		Vdc	119
	Overvoltage		Vdc	150
	Overvoltage Recover		Vdc	149
Pv Input	Charge Current (Optional)		A	30
	Number of string (Optional)			2
	Overcharge Protection		Vdc	130
	Overcharge Recover		Vdc	119
	Lightning Protection(Optional)			Varistor/Arrester
Grid Bypass	Bypass Voltage range		Vac	230/110 ± 15%
	Bypass Grid frequency		Hz	50/60
AC Output	Rated Output Voltage		V	230V/115
	Voltage Accuracy		%	± 3%
	Rated Output  Frequency		Hz	50/60
	Frequency Accuracy		Hz	50/60± 0.04
	Output Wave			Pure sine wave
	Power Factor		%	80%
	Inverter Efficiency		%	≥94%
	Peak factor			3:01
	Total Harmonic Distortion THD (Iac)		%	Total <3% (Linear load)
	Dynamic Response		%	5%
	Output Current		A	14
	Overload Capacity			120% 1 min
System	Insulation			1500Vac 1min
	Ambient temperature of using			-25+60
	Environmental humidity		%	0~90%,Non-condensing
	Altitude		M	< 6000
	Earthquake Ability		g	0.2
	Noise level		dB	<45dB at 1 meter
	Protected			Reverse polarity, shortage, over heat
Communication& Mechanics	Communication interface			Electrical isolationRS485/232
	Optional			Ethernet/GPRS
	Display			Mechanical watch And /LED/LCD Display
	Waterproof and Dustproof Class			IP20(Indoor
	Reference to size		mm	450 X 550 X 800
	Weight		Kg	80Kg
