Customized Linear Actuators
US$ 46.7 - 58
MOQ: 20 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Summit
Model Number:
D-42A
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Tubular Mini Linear Actuator for Electric DoorUS$ 80 - 120MOQ: 20 Pieces -
Customized Linear Actuators for SkylightUS$ 46.7 - 58MOQ: 20 Pieces
-
Wholesale High-speed Waterproof IP65 Mini Linear Actuator With Two Limited Switches for Automatic EquipmentUS$ 18 - 30MOQ: 1 Piece
-
12v/24v/36v/48v High Speed Linear Actuator With Limited Switch IP65 for Automatic Equipment Made in China(mainland)US$ 18 - 30MOQ: 1 Piece
-
Linear Actuator With 12v/24v/36v/48v Voltage Mini Linear Actuator Made in China(mainland)US$ 18 - 30MOQ: 1 Piece
Place of Origin
Zhejiang, China
Brand Name
Summit
Model Number
D-42A
Specifications
1. tube diameter: 42mm2. User friendly
3. Simple installation
4. Low noise
5. High rigidity 6. Competitive price
Feature
Model |
LA-D42 |
Tube diameter |
Ø 42mm |
Input Voltage |
12/24VDC |
Max Load Capacity |
2000N |
Stroke Length |
50mm-700mm |
Speed at No Load |
5.3mm/s -- 15mm/s
|
Mini installation dimension |
Lmin= Stroke+ 250mm±2mm(Stroke <200) Lmin= Stroke+ 265mm±2mm(Stroke > 200) |
Duty Cycle |
10%( 2 minutes on 18 minutes off) |
Operation Temperature |
-26ºC~65ºC (-15ºF~150ºF) |
Limit Switch |
Built-in (Factory Preset) Not movable |
IP Grade |
IP66 |
Noise |
<50 db |
Color |
Black or grey |
Feature
MODEL |
LOAD(N) |
NO LOAD SPEED/ LOAD SPEED MM/S |
PITCH |
RATIO |
CURRENT UNDER LOAD(24V) |
LA-D42 |
750 |
15/8 |
7.5 |
1:50.9 |
1.8A |
LA-D42 |
1500 |
8/4.5 |
5 |
1:71.2 |
1.7A |
LA-D42 |
2000 |
5.3/3.5 |
5 |
1:99.5 |
1.5A |
Drawing
Usage
